Urbane II Wall Faced Close Coupled Toilet Suite
Verified by manufacturer over a year ago
High performance 4.5/3 litre rimless Vitreous China Toilet. Wall faced close coupled toilet suite.
Application
- Suitable for domestic and commercial applications.
- Suitable for Ambulant AS1428.1-2021 installation applications.
Description
Urbane II toilets have a contemporary low-profile design to match the rest of the Urbane II bathroom collection. With GermGard® antimicrobial protection to the seats and option for coloured seat hinge caps. Some of its significant features include:
- WELS 4 star rated, 4.5/3L (3.5L avg/flush).
- Caroma CleanFlush® rimless technology is a patented Australian design that provides a whole bowl clean with no splashback.
- Back entry (746350W) or bottom inlet (746250W) cistern.
- Universal trap (UniTrap) for S or P trap installations.
- S Trap 60 to 200mm, P Trap 185mm.
- Hygenic, easy to clean and water efficient toilet.
- Vogue soft close toilet seat with quick release function for easy cleaning.
General information
Color | White Manufacturer guidanceWith optional coloured flush buttons and seat hinge caps to match Urbane II tapware. |
Finish | Smooth. |
Material | Vitreous china. |
Length | 655 mm |
Width | 360 mm |
Warranty description | 20 years. |
Uniclass | |
NATSPEC National Classification System | 0811 Sanitary Fixtures |
SpeedSpec | 15410 Plumbing Fixtures |
SpecPack | 15410 Plumbing Fixtures |
Specification data - WC suites
Water Efficiency Labelling and Standards Scheme (WELS) | |
Standard | To AS/NZS 6400. |
Rating | 4 star. |
Use | Accessible to AS 1428.1. |
Form | Wall faced. |
Rim configuration | Without rim. |
Materials | Vitreous china. |
Finish and colour | White. |
Sizes | |
Cistern capacity | 4.5/3 L dual flush. |
Pan height | 440 mm. |
Integral accessories | UniOrbital® connector. |
Execution | The installation of the toilet suite shall be in accordance with the normal minimum drainline grade requirements in AS/NZS 3500.2. |
Seat | Soft close quick release thermoset toilet seat with GermGard® Antibacterial Protection. Guidance for specification option: Optional seat caps are available in 3 finishes, Brushed Brass (BB), Black (B) or Gunmetal Grey (GM). Manufacturer guidanceProvided as standard with seat caps in Stainless Steel (SS). |
Dimensions | 655 l x 360 w (mm). |
Fixing | D82 fixing brackets. Guidance for specification option: Supplied. Pan should be bedded with an acetic cured silicone sealant. Bedding to mortar. Guidance for specification option: Pan should be fixed to the floor with a sand cement mixture of 3:1 to a depth of 60 mm. |
