Gypsum board partition systems
Find and specify gypsum board partition systems from top manufacturers with NBS Source. Browse 1190 products that are ready to use on your projects. Classification Ss_25_10_30_35.
Can't find what you're looking for?
Industry averages:BETA
Recently verified
Showing 829-864 of 1190
GypWall Twin Frame Braced - L216011 (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc SoundBloc 12.5mm with an outer layer of Gyproc Habito 12.5mm fixed to outside faces of two Gypframe 48 S 50 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 1200mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 3000mm.
GypWall Twin Frame Braced - A216001 (B) (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc Plank 19mm with an outer layer of Gyproc SoundBloc 12.5mm fixed to outside faces of two Gypframe 48 S 50 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 1200mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 5000mm.
GypWall Twin Frame Audio - A326017A (A) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. Four layers of 100mm Isover Cladding Roll 40 and two layers of 100mm stone mineral wool (min. 62kg/m3) in the cavity. For heights up to 4200mm.
GypWall Twin Frame Audio - A326019A (B) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. Three layers of 100mm Isover Cladding Roll 40 and two layers of 100mm stone mineral wool (min. 62kg/m3) in the cavity. For heights up to 8000mm.
GypWall Single Frame - A206A290S (B) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 12.5mm each side of Gypframe 92 AS 50 AcouStuds at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 5000mm.
GypWall Twin Frame Audio - A326019B (B) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe GAB3 Acoustic Braces at 3300mm centres. Three layers of 100mm Isover Cladding Roll 40 and two layers of 100mm stone mineral wool (min. 62kg/m3) in the cavity. For heights up to 8000mm.
GypWall Twin Frame Audio - A326003A (B) (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc Plank 19mm with an outer layer of Gyproc SoundBloc 12.5mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. 100mm Isover Cladding Roll 40 in the cavity. For heights up to 5000mm.
GypWall Twin Frame Audio - A326003B (A) (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc Plank 19mm with an outer layer of Gyproc SoundBloc 12.5mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe GAB3 Acoustic Braces at 3300mm centres. 100mm Isover Cladding Roll 40 in the cavity. For heights up to 4200mm.
GypWall Staggered - A233006S (A) (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc SoundBloc 15mm each side of Gypframe 92 I 90 ‘I’ Studs in Gypframe 148 FEC 50 Folded Edge Standard Floor & Ceiling Channel. Gypframe SC2 Spacer Clips and alternate studs staggered in the channel at 300mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 4200mm.
GypWall Single Frame - H206035 (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc WallBoard 12.5mm with an outer layer of Glasroc H TileBacker 12.5mm each side of Gypframe 48 S 50 'C' Studs at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 3000mm.
GypWall Twin Frame Audio - A326016A (A) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. 100mm Isover Cladding Roll 40 in the cavity. For heights up to 4200mm.
GypWall Single Frame Enhanced - Q606065S (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc DuraLine 15mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 80mm Isover Modular Roll in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 3800mm.
GypWall Twin Frame Independent - A216014 (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 48 I 50 ‘I’ Stud frameworks with studs at 600mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 2800mm.
GypWall Twin Frame Braced - A216008 (A) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 48 S 50 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 1200mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4200mm.
GypWall Twin Frame Audio - A326013A (C) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. Two layers of 100mm Isover Cladding Roll 40 in the cavity. For heights up to 9000mm.
GypWall Twin Frame Audio - A326019B (A) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe GAB3 Acoustic Braces at 3300mm centres. Three layers of 100mm Isover Cladding Roll 40 and two layers of 100mm stone mineral wool (min. 62kg/m3) in the cavity. For heights up to 4200mm.
GypWall Twin Frame Audio - A326013A (B) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 3600mm centres. Two layers of 100mm Isover Cladding Roll 40 in the cavity. For heights up to 8000mm.
GypWall Staggered - A233026 (A) (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc SoundBloc 15mm each side of Gypframe 92 I 90 ‘I’ Studs in Gypframe 148 FEC 50 Folded Edge Standard Floor & Ceiling Channel. Gypframe SC2 Spacer Clips and alternate studs staggered in the channel at 300mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4200mm.
GypWall Single Frame - A206231S (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 4000mm.
GypWall Single Frame - A206149S (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc WallBoard 12.5mm each side of Gypframe 146 S 50 'C' Studs at 600mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 4000mm.
GypWall Single Frame - A206016 (B) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc WallBoard 15mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. For heights up to 4900mm.
GypWall Single Frame - A206111 (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc FireLine 12.5mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
GypWall Single Frame Enhanced - Q606A063S (EN)
Verified 5 months ago
British Gypsum
Inner layer of Gyproc SoundBloc 12.5mm with an outer layer of Gyproc DuraLine 15mm each side of Gypframe 70 AS 50 AcouStuds at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 3000mm.
GypWall Single Frame Enhanced - Q606066S (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc DuraLine 15mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 75mm Isover Acoustic Slab in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 3800mm.
GypWall Single Frame Enhanced - Q606063S (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc DuraLine 15mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 3800mm.
GypWall Twin Frame Audio - A326016B (A) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe GAB3 Acoustic Braces at 3300mm centres. 100mm Isover Cladding Roll 40 in the cavity. For heights up to 4200mm.
GypWall Single Frame - A206A306 (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc SoundBloc F 15mm each side of Gypframe 92 AS 50 AcouStuds at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
GypWall Single Frame - A206230 (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 12.5mm each side of Gypframe 70 S 50 'C' Studs at 600mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity. For heights up to 4000mm.
GypWall Single Frame - A206A180 (C) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc FireLine 15mm each side of Gypframe 146 AS 50 AcouStuds at 600mm centres. For heights up to 8100mm.
GypWall Single Frame - A206067A (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc FireLine 12.5mm each side of Gypframe 48 S 50 'C' Studs at 600mm centres. For heights up to 3400mm.
GypWall Single Frame - A206028 (A) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc WallBoard 15mm each side of Gypframe 146 S 50 'C' Studs at 600mm centres. For heights up to 4200mm.
GypWall Single Frame - A206A285 (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc FireLine 15mm each side of Gypframe 92 AS 50 AcouStuds at 600mm centres. For heights up to 4000mm.
GypWall Single Frame - A206270S (A) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm each side of Gypframe 92 S 50 'C' Studs at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 4200mm.
GypWall Twin Frame Audio - A326017B (A) (EN)
Verified 5 months ago
British Gypsum
Three layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 92 S 10 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe GAB3 Acoustic Braces at 3300mm centres. Four layers of 100mm Isover Cladding Roll 40 and two layers of 100mm stone mineral wool (min. 62kg/m3) in the cavity. For heights up to 4200mm.
GypWall Single Frame Enhanced - Q606A044S (EN)
Verified 5 months ago
British Gypsum
One layer of Gyproc DuraLine 15mm each side of Gypframe 70 AS 50 AcouStuds at 600mm centres. 25mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 4000mm.
GypWall Twin Frame Braced - A216009S (B) (EN)
Verified 5 months ago
British Gypsum
Two layers of Gyproc SoundBloc 15mm fixed to outside faces of two Gypframe 48 S 50 ‘C’ Stud frameworks with studs at 600mm centres, cross braced using Gypframe 99 FC 50 Fixing Channel at 1200mm centres. 50mm Isover Acoustic Partition Roll (APR 1200) in the cavity with 2mm Thistle MultiFinish on each side. For heights up to 6200mm.
Showing 829-864 of 1190
