The LP-STAR System supplies reliable power to escape luminaires and exit sign luminaires (230 V a.c/ 220 V d.c) according to EN 50171 and BGV A3. It provides up to 540 watts of power from a 24 V battery.

Features and benefits:

Compliant with EN 50171.
Provides up to 540 watts of power from a 24 V battery.
Designed for distributed power supply to CEAG emergency exit and safety luminaires with STAR technology.
Suitable for emergency lighting systems according to DIN VDE 0100-718, DIN EN 50172 and E DIN VDE 0108-100.
No special requirements concerning the housing on functionality in case of installation in separate fire areas.
Cost savings as E30 wiring is not required because devices are installed in separate fire areas.
Natural ventilation is generally sufficient due to the closed form and low capacity of batteries.
Additional safety even in case of fire due to the decentralised arrangement of systems.
Simple operation and commissioning based on a smart programming and operating plan.
230 V a.c./ 220 V d.c. supply voltage selectable to power the escape luminaires and exit sign luminaires to comply with architectural issues.
Standard integrated phase monitor for monitoring general power supply conditions.
Additional phase monitor input including line monitoring for an external phase monitor.
Standard eight digital 230 V input channels for switching each luminaire separately, for example, freely programmable.
Optional web module for the automatic monitoring of LP-STAR according to EN 62034.
Optional CG-S interface for connecting to the CG-S bus for CGVision or master/slave operation for connecting several LP-STAR devices.
Shorter inspection time using the CEWA GUARD technology, automatic function monitoring of up to 20 luminaires per circuit.
Reduced installation costs due to the STAR technology, freely programmable mixed operation of switching modes per luminaire in a single circuit without an additional data cable.
Automatic luminaire search function.
Plain text display at the control module for all luminaires.
Flexible data memory for the test log and device configuration using the Secure Digital card.
Absence of retroactive effect of different circuits in case of a short-circuit due to the automatic, selective shut-off function.
EoL shut-off, programmable as standard.
