Summary
Thermally modified Scandinavian Scots Pine cladding.
-
-
Application

Suitable for use as external timber cladding.

-
-
Description

Thermopine® is a timber with enhanced stability and durability, produced by thermally modifying Scandinavian grown Scots Pine using only heat, steam and pressure.



Thermopine® has a uniform chocolate-brown colour tone which will quickly weather to grey if left uncoated. Due to its enhanced stability, the product is suitable for factory coating in a choice of colours. Boards display attractive, tight grain figuring with an abundance of live (structurally sound) round and splay knots, some of which may display cracks and chipped-off edges after machining, an occasional dead knot cannot be ruled out.



The appearance after factory coating is largely determined by which surface is opted for. An opaque coating means the knots and figuring will be less visible. When coating thermally modified timber using translucent coating systems, some lightening of the colour tone is to be expected over time, particularly when lighter shades are selected. This is to do with the natural weathering of the timber.



Features and benefits:

  • Durability Class 2 as per BS EN 350.
  • Lengths up to 5.7 m.
  • Excellent price/ performance ratio.
  • UKCA marked to EN 14915.
  • PEFC certified.
-
-
Product certifications
-
-
Digital objects
-
-
Color
Grey, Black, Brown
-
-
Finish
Brushed, Oiled, Painted, Other
-
-
Material
Timber
-
-
Shape
Rectangle
-
-
Length
Bespoke
-
-
Width
92 mm, 117 mm
-
-
Height
20 mm, 21 mm
-
-

Specification

Classification data
Breather membrane
-
-
-
Material
Supplied by others.
-
-
Fasteners
Supplied by others.
-
-
Cladding support
-
-
-
Counter battens
RWB002 - Thermopine 45 x 20 mm.
-
-
Battens
RWB003 - Thermopine 41/ 46 x 42 mm.
-
-
Fasteners
KompeFix® flexible ventilation strips and GoFix® MS II 5.0 x 120 mm screws with SC 7® coating for load-bearing connections. F-BohrFix® 3.2 x 40 mm stainless-steel screws for non-load-bearing connections.
-
-
Cavity fire barriers
-
-
-
Horizontal
Not required., Securo FIREBREATHER® cavity barrier.
-
-
Vertical
Not required.
-
-
Weatherboarding
-
-
-
Material
Thermopine® – Thermally modified Scots Pine, Pinus sylvestris.
-
-
Fasteners
L-GoFix® MS A2 stainless-steel screws and KompeFix®.
-
-
System accessories
Not required., KompeFix® flexible ventilation strips.
-
-

Additional properties

Density
420 kg/m³.
-
-
Surface finish
Microtex®., Planed., Wire brushed.
-
-
Board profile
RW014.
-
-
Reaction to fire
Euroclass F (Untested).
-
-
Durability
To BS EN 350, Durability Class 2.
-
-
Applied finish
SiOO:X (light grey)., SiOO:X (mid grey)., SiOO:X (original)., Teknos paint coating, RAL 7016., Teknos paint coating, RAL 7021., Teknos paint coating, RAL 7043., Teknos paint coating, RAL 9005., Teknos paint coating, opaque., Woca oil, black., Woca oil, teak.
-
-
Length
-
-
-
Width
92 mm., 117 mm.
-
-
Depth
20 mm.
-
-

Sustainability data

Country of material origin
Finland
-
-
Country of product manufacture
Finland
-
-
Material
Timber
-
-
A1–A3 ('Production stage')

Embodied carbon as defined in BS EN 15804

Normalized unit
-
-
-
Declared unit
770 kg CO₂ eq/unit

Certified

-
-
Recyclability
Yes
-
-
