7500 Series (Aluminium) Tree Pit Cover
Verified by manufacturer 1 month ago
Aluminium tree pit covers for cars and light delivery vehicles up to 5 tonne (5000 kg) pneumatic tyre wheel load.
Application
Suitable for interior and exterior floors.
Description
Aluminium medium duty tree pit cover for up to 5000 kg tonne pneumatic tyre wheel loads (cars and light delivery vehicles) on hard floor surfaces providing easy access to tree root ball.
Features and benefits:
- Available with a top edge seal to help prevent dirt, grout or grinding waste ingress.
- Provides easy access to tree root ball using lifting keys.
- Facilitates easy ongoing maintenance of trees.
- Resistant to rust and corrosion.
- Manufactured in accordance with BS EN ISO 9001.
- Removable central stainless steel tree rings.
- Weight (when filled): 155 kg/m².
- Overall frame size: Clear opening size plus 120 mm.
General information
Color | Silver |
Finish | Galvanized |
Material | Aluminium |
Shape | Square |
Length | 1020 mm |
Width | 1020 mm |
Height | 75 mm |
Uniclass | |
CAWS | Q10/305 Tree grilles and surrounds Q50/262 Tree grilles Q50/30 Street furniture |
Product range |
Specification data - Tree grilles
Material | Guidance for specification option: Steel baseplate and reinforcement. Galvanized carbon steel support beams and pockets. |
Finish | Aluminium. |
Colour | Silver. |
Size | 230 x 1020 mm.Manufacturer guidanceOverall frame size. |
Internal aperture | 100 x 900 mm. |
Accessories | None.Support beam pockets.Sets of combined lifting/ securing keys.Cover skate lifting device. |
Base plate material | Galvanized steel. Guidance for specification option: Standard. Stainless steel, grade 1.4301 (304). Stainless steel, grade 1.4401 (316). |
Support beam pockets | Not required. Recessed. Guidance for specification option: For use where support beams are required. Surface mounted. Guidance for specification option: For use where support beams are required. |
Depth | 75 mm. |
Sustainability data
Material | Aluminium |
Literature
Howe Green Tree Pits and Tree Grilles
