A1400 Automatic Sliding Door Operator with SKR35 Door Profiles - RC3 Rated Door - Burglar Resistant Sliding Door

Name: A1400 Automatic Sliding Door Operator with SKR35 Door Profiles - RC3 Rated Door - Burglar Resistant Sliding Door
Brand: FAAC Entrance Solutions UK
SKU: rGULXUEHhVvmNm7uPxWaBD

Verified by manufacturer 4 months ago

Single - FAAC A1400 AIR 140 mm sliding door operator

FAAC Entrance Solutions UK

Third party certifications:

ADSA
Certificate type
CHAS
Certificate type
Constructionline
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
ISO 45001 Health and Safety Management
Certificate type
UKAS
Certificate type

FAAC EN 1627/ RC3 burglar-resistant framed sliding single or double door leaf system with A1400 sliding door operator.

Jump to:

BOS

+44 (0)333 006 3443 Website

Application

Automatic burglar-resistant sliding single or double door.

Description

FAAC EN 1627/ RC3 burglar-resistant framed sliding single or double door leaf system with A1400 sliding door operator.

Features and benefits:

Available as a single or double door system and part of a range of A1400 door operators.
Opening width: 850–1150 mm (single); 1000–2400 mm (double).
Supports door leaf up to 250 kg (single); up to 180 kg each (double).
System including normal installation to comply with BS 7036-0:2014 and BS EN 16005:2012.
Monitored emergency escape opening and threshold presence detection safety system, with 24 V d.c. E1/2SL monitored battery pack.
Exclusive intelligent energy saving function eliminates cross traffic opening, optimizing opening widths and hold open times.
To permit safe passage between closing doors, the doors go into reverse mode if an obstruction is detected, and then start moving again slowly to check if the obstruction has cleared.
Automatic adjustments: Determination of opening and closing positions. Selection of ideal speed, acceleration and deceleration.
Protection sensor monitoring.
Standard one year warranty (can be extended subject to quotation).

Manufacturer’s Declaration of Conformity

Tested to: EN 1627:RC3, EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.

General information

Color	Silver Bronze Other Clear
Finish	Anodized Powder-coated
Material	Glass
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_24_80 Sliding door and partition setsPrimary
CAWS	L20/490 Automatic doors

Specification data - Sliding door and partition sets

Performance	Internal. External.
Arrangement	Top hung single door, left-hand opening. Top hung single door, right-hand opening.
Track system	FAAC A1400 AIR 140mm sliding door operator (top track). Manufacturer guidance With unique Energy Saving function providing automated operation. See below for additional track properties including finish options.
Door leaves	-
Construction	60 mm wide door stiles; P5A anti-bandit safety glass. Manufacturer guidance FAAC SKR35 reinforced framed sliding door.
Finish and colour	Silver anodized. Bronze anodized. FAAC powder coat finish, RAL. Guidance for specification option: Consult manufacturer for options and insert requirements.
Operation	Combined uni-directional and threshold presence detection entry/exit activator. Elbow push pads for entry/exit. Access control for entry and elbow push pad for exit. Contactless activation for entry/exit.
Accessories	None. Morning entry switch. Anti-panic breakout system APN. Manufacturer guidance See also Locking mechanism and Activation for further options.

Dimensions	Guidance for specification option: Insert requirements, subject to maximum door leaf weight of 200 kg: Opening width: 850–1150 mm. Door height, operator wall mounted: 2100–2315 mm.
Mode of operation	Digital FAAC SDK EVO with seven-mode selector. Digital FAAC LK EVO with six-mode selector. Key switch FAAC EVO with five-mode selector.
Door protection	Finger protection - flush glazed externally and internally. Finger protection - flush glazed externally only.
Safety	Sidelight - monitored presence detection. Sidelight - full-height hinged framed pocket screen.
Additional requirements	Sidelights; flush glazed, one panel. Sidelights; flush glazed, two panels. Sidelights, flush glazed - sliding over walls/ sidelights by others. Guidance for specification option: Insert requirements. Not required.
Lock	Mechanical hook bolt lock: EN 1627: RC3-rated multi-point locks mounted into the vertical stiles.
Locking mechanism	Fail safe (electric). Fail secure (electric). Bi-stable (electric). Not required. Manufacturer guidance See also Cylinder and Lock.
Track finish	To match door. Silver anodized. Bronze anodized. FAAC powder coat finish, RAL. Guidance for specification option: Consult manufacturer for options and insert requirements.
Standard	Tested to EN 1627:RC2, EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.
Threshold	Flush-mounted floor guide with anti-tamper device. Guidance for specification option: Prevents the door leaves from being forced open.
Fixing	FAAC beam mounted. Wall mounted, beam by others. Guidance for specification option: Insert details.
Control system	Manufacturer's standard. Guidance for specification option: Monitored emergency escape opening and threshold presence detection safety system, with 24V DC E1/2SL Monitored battery pack. Unique intelligent energy saving function eliminates cross traffic opening, optimizing opening widths and hold open times. To permit safe passage between closing doors, the doors go into reverse mode if an obstruction is detected, and then start moving again slowly to check if the obstruction has cleared. Automatic adjustments: Determination of opening and closing positions. Selection of ideal speed, acceleration and deceleration. Protection sensor monitoring. Switch-mode power supply to allow installation and commissioning between 110–240 V. Manufacturer guidance See also: Activation: See Operation for options. Morning entry switch: See Accessories for options. Sidelight safety: See Safety for options. Operation mode selector: See Mode of operation for options.
