A1400 Automatic Sliding Door Operator - Automatic Sliding Door Operator

Name: A1400 Automatic Sliding Door Operator - Automatic Sliding Door Operator
Brand: FAAC Entrance Solutions UK
SKU: r6XhnyPYYQCmzigeY7jieL

Verified by manufacturer 4 months ago

Single - FAAC A1400 AIR 140 mm sliding door operator

FAAC Entrance Solutions UK

Third party certifications:

ADSA
Certificate type
CHAS
Certificate type
Constructionline
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
ISO 45001 Health and Safety Management
Certificate type
UKAS
Certificate type

Automatic sliding door operator for single and double doors.

Jump to:

BOS

+44 (0)333 006 3443 Website

Application

Automatic sliding door operator for single and double doors.

Description

Automatic sliding door operator for single and double doors.

Features and benefits:

Available in single and double models.
Opening width: 700–1500 mm (single); 800–3000 mm (double).
System including normal installation to comply with BS 7036-0:2014 and BS EN 16005:2012.
Monitored emergency escape opening and threshold presence detection safety system, with 24 V d.c. E1/2SL Monitored battery pack.
Exclusive intelligent energy saving function eliminates cross traffic opening, optimizing opening widths and hold open times.
Standard one year warranty (can be extended subject to quotation).

Manufacturer’s Declaration of Conformity

Tested to: EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.

General information

Color	Silver Bronze Other
Finish	Anodized Powder-coated
Shape	Rectangle
Warranty description	One year

Uniclass	Pr_30_36_36_23 Door track and running gearPrimary
CAWS	L20/490 Automatic doors P21/10 Door track and running gear P21/350 Door track and running gear

Specification data - Door track and running gear

Standard	Tested to EN 60335-1, EN 60335-2, EN 61000-6-2, EN 61000-6-3, EN ISO 13849-1, EN ISO 13849-2, EN ISO 12100 and EN 16005.
Classification grades (minimum)	-
Durability	Manufacturer's standard.
Door mass	3. Guidance for specification option: Up to 200 kg.
Corrosion resistance	Manufacturer's standard.
Category of door-opening action	1.
Initial friction	Manufacturer's standard.
Form	Silver anodized top track with Energy Saving function. Bronze anodized top track with Energy Saving function. FAAC powder coat finish top track with Energy Saving function. Guidance for specification option: Consult manufacturer for options and insert colour requirements (RAL). Manufacturer guidance Consult manufacturer for full details.
Integral accessories	None. Morning entry switch. Manufacturer guidance See also Locking mechanism and Activation for further options.

Locking mechanism	Fail safe. Fail secure. Bi-stable. Not required.
Dimensions	Opening width: 700–1500 mm.
Activation	Combined uni-directional and threshold presence detection entry/exit activator. Elbow push pads for entry/exit. Access control for entry and elbow push pad for exit. Contactless activation for entry/exit.
Configuration	Left-hand opening. Right-hand opening.
Mode of operation	Digital FAAC SDK EVO multi-mode selector and configurator tool. Digital FAAC LK EVO with LED diagnostic and six-mode selector. Illuminated key switch FAAC EVO with five-mode selector.
Safety	Sidelight - monitored presence detection. Sidelight - full-height pivoted pocket screen(s) by others.
