A4 Stainless Steel Composite Panel Fasteners
Verified by manufacturer 6 days ago
DF5-SSA4-HT-6.3
DF5-SSA4-HT-6.3
A4/316 stainless steel self-drilling fasteners for installing insulated sandwich panels.
Application
For mechanically fixing composite roof and wall panel systems.
Description
A4/316 grade stainless steel self-drilling fasteners for roofing and cladding.
Features and benefits:
- To suit panels up to 300 mm thick.
- Warranted fasteners with £20 million UK insurance cover.
- A4/ 316 stainless steel for optimum resistance to corrosion.
- Suitable for marine environments.
- Bi-metal manufactured for superior drilling performance.
- Good pull-out and shear performance.
- High thread provides optimal clamping force to top sheet.
- Purpose designed and precision manufactured.
General information
Color | Beige Black Blue Bronze Brown |
Finish | Mill Powder-coated |
Material | Stainless steel |
Shape | Other |
Length | Manufacturer guidanceTo suit 300 mm+ panel thicknesses. |
Width | 5.5 mm 6.3 mm |
Warranty description | 40 year Manufacturer guidanceUp to 40 years. |
Uniclass | |
CAWS | H92/120 Rainscreen cladding H43/120 Metal insulating sandwich panel Z20/380 Screws H20/10 Sheet cladding H43/10 Metal insulating sandwich panel H20/150 Sheet cladding (attached to metal support systems) |
SKU Code | SSA4-HT / SSA4-P-HT |
Specification data - Self-drilling screws
Material | Stainless steel. Guidance for specification option: A4 grade (316). |
Finish | Organic coating. |
Head type | Hexagonal. |
Size | |
Diameter | M6.3. |
Length | 85 mm. 115 mm. 135 mm. 155 mm. 185 mm. 230 mm. 275 mm. 330 mm. 350 mm. |
Washer | No washer. |
Sustainability data
Material | Stainless steel |
Literature
Literature type
Brucha Insulated Panels Selector Guide
Building Envelope Fastener Specification Guide 2024
Eurobond Europanel Selector Guide
Eurobond Rainspan Selector Guide
Eurobond Rockspan Selector Guide
Eurobond Roofspan Selector Guide
Kingspan QuadCore KS1000 RW Selector Guide
Kingspan QuadCore Roofliner KS1100RL Selector Guide
TATA Trimapanel Selector Guide
TATA Trisomet Selector Guide
Trimo Trimoterm FTV Selector Guide
Case studies
Curious Brewery
