Activity Track - Children's Multiplay Activity Structure

Name: Activity Track - Children's Multiplay Activity Structure
Brand: Redlynch Leisure Installations Ltd
SKU: 2KSxmpE3e3XTcAh1w4vbwm

Verified by manufacturer 28 days ago

Third party certifications:

Children's multifunction/ multiplay activity structure.

Jump to:

Application

Children's multifunction/ multiplay activity structure for public children's playgrounds.

Suitable for users age 4+, up to 45 users.

Children's multifunction/ multiplay activity structure.

Features and benefits:

Material	Timber High pressure laminate (HPL) Stainless steel
Shape	Other Guidance for specification option: Ship theme.
Length	11320 mm
Width	9000 mm
Height	4150 mm
Warranty description	15 year

Uniclass	Pr_40_30_61_18 Combined play structuresPrimary
CAWS	Q52/340 Combined play structure

Standard	To EN 1176-1 and EN 1176-3 (TÜV).
Age range	4+.
Highest platform height	Manufacturer's standard. Guidance for specification option: Consult manufacturer for details.
Components	Balancing sections: Three. Bridges: Four. Climbing sections: Seven. Play panel: One. Roofs: Two. Slides: Four. Towers: Six.
Materials	Metal/ wood/ HPL. Guidance for specification option: Consult manufacturer for details.
Finish as delivered	-
Finish type	Manufacturer's standard.
Film thickness (minimum)	Manufacturer's standard.
Colours	Guidance for specification option: Consult manufacturer for options and insert requirements.

Plan Size	11.32 x 9.0 m. Required area (overall): 15.37 x 12.5 m.
Overall height	4.15 m. Required height: 5.15 m.
Post foundations	Manufacturer's standard. Guidance for specification option: Consult manufacturer for details.
Weight	Manufacturer's standard. Guidance for specification option: Heaviest component: 164 kg.
Technical characteristics, other	Impact area: 109 m². Falling space area: 114 m². Maximum free fall height: 2.57 m. Up to 45 users.

Contains Red List materials	No
Country of material origin	Finland
Country of product manufacture	Finland
Recyclability	All parts of this product are recyclable
