Aluminium sliding door system - ASE 60 - Aluminium Sliding Door
Verified by manufacturer 6 months ago
ASE60 Unit Type with Single Track Design
ASE60 Unit Type with Single Track Design
Panorama design sliding door system.
Application
Suitable for use where there is need for thermal insulation and slimline face widths.
Description
Modular, scalable, sliding and lift-and-slide system with concealed fittings, slimline interlock face widths, certified burglar resistance and thermal insulation.
Features and benefits:
- Thermally insulated sliding system with maximum transparency and light penetration.
- Touch button, handle-free design with clean lines.
- Concealed outer frame, profile-integrated drive and locking system.
- Rail system can be easily removed and the roller replaced without removing the moving vent.
- Straightforward fittings installation for cost-effective fabrication.
- Manually-operated “unlocking for maintenance” in the event of a power cut.
Standards:
- DIN EN 13115.
- DIN EN 12400.
- DIN EN 1670.
- DIN EN ISO 10077-2.
- DIN EN 12208.
- DIN EN 12207.
- DIN EN 12210.
General information
Color | Other Guidance for specification option: All colours are available. |
Finish | Anodized Powder-coated |
Material | Aluminium Glass |
Shape | Rectangle Square |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L20/60 Doors L20/520 Sliding doors |
Specification data - Sliding door and partition sets
Performance | Insulated. |
Track system | Single track. |
Operation | Manual.Powered. |
Accessories | Smart stop.Smart close. |
Execution | Installing hardware. |
Product Reference | ASE60 Unit Type with Single Track Design |
Operating forces | To EN 13115, Class 1. |
Durability Class | To EN 12400, Class 3. |
Operating temperature | -20 °C to +50 °C. |
Corrosion resistance | To EN 1670, Class 4. |
Thermal insulation | To EN ISO 10077-2, from 1.1 W/(m²K). |
Watertightness | To EN 12208, E900. |
Air permeability | To EN 12207, Class 4. |
Resistance to wind load | To EN 12210, C35/B5. |
Face width | From 40 mm. Guidance for specification option: In the interlocking section. |
Glass thickness | Up to 40 mm. |
Weight | 500 kg. Guidance for specification option: Manual. 600 kg. Guidance for specification option: Automated. |
Width | 621–3500 mm. Manufacturer guidanceLarge vent width. |
Height: | 1000–3500 mm. Manufacturer guidanceLarge vent width. |
Depth | 140 mm. 152 mm. |
Corners | Internal and external available. Manufacturer guidance90 degree corner features. |
Acoustic performance rating | 41 db RW. |
Durability | Up to 1 million cycles. |
Burglar resistance | RC2. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | United Kingdom |
Material | Aluminium Glass |
Recyclability | cradle2cradle |
