Anhydrite Liquid Screed - Gypsol Modular - High Strength Screed

Name: Anhydrite Liquid Screed - Gypsol Modular - High Strength Screed
Brand: LKAB Minerals
SKU: aS2awAGdJMWRUtmVsHeiGg

Verified by manufacturer 1 day ago

LKAB Minerals

Product certifications:

BBA Agrément Certificate
Certificate type
EPD
Certificate type

Gypsol Modular, a screeding solution, especially for use in modular construction either on or off-site particularly when you desire a lightweight construction.

Jump to:

0800 622 6023 Website

Application

This liquid screed is designed for modular construction, requiring a concrete feel and structure but where transport and site requirements dictate a lighter-weight structure. In particular for constructions where structural security is an essential design requirement. Some examples are:

Prison buildings.
Hospital operating theatres.

Gypsol Modular can be used over lightweight steel frames as well as over timber. Also, the screed offers high early flexural strength, which allows:

The rapid movement of in factory units,
And early trafficking of on-site screeds.

The screed is suitable for the encapsulation of an underfloor heating system, either electric or warm water. The material can be used to produce a smooth, flat, and level floor to form the subbase for subsequent floor coverings for internal floors.

Specially trained screeders pump the screed into place by using specialized equipment. As a result, Gypsol Modular screed solution provides a cost-effective and environmentally friendly alternative to cement-based screeds and timber floors. It can also be used with the unique Gypsol Rapide fast-drying additive to produce drying times of just 14 days at 50 mm deep in the correct drying conditions.

Description

Gypsol Modular is suitable for on- and off-site modular construction, including residential and commercial properties with lightweight and durable floors.

Gypsol Binder is an integral component of Gypsol Modular, a liquid screed that provides a concrete feel to a timber or lightweight steel floor. Gypsol Modular can be used for both on-site and offsite construction processes and placed with or without an underfloor heating system. Offsite screeded modular units may be lifted using suitable lifting equipment after just 72 hours. Gypsol Modular is suitable for receiving all types of floor coverings.

Features and benefits:

Rapid application.
Assured high strength.
Minimum Ca-C30 – F6
Off-site modular units can be moved after typically three days
Low shrinkage
Reduced risk of plastic cracking
Suitable for use in modular construction
Thin screed sections: typically, 35 mm on LEWIS Dovetail sheet, 25 mm cover to underfloor heating pipes.
Fast drying: 28 days natural drying*, 13 days forced drying*.
Can be used with Rapide Additive to offer 14 days drying.
Rapid commissioning of underfloor heating.
Underfloor heating can be commissioned and run after just seven days.
No reinforcement nor fibres required.
No curing agents required.
Fully self-compacting and high-density.
Offers 80 kg/m² density at just 40 mm.
Rapid return to service of work areas.
Foot traffic after only 48 hours.
Full loading after just seven days.

*Independently tested and based on 50 mm depth at 20˚C and 60% RH. Full test data is available on request.

General information

Color	White Guidance for specification option: Off white.
Finish	Smooth
Material	Calcium sulphate
Shape	Formless
Length	Bespoke
Width	Bespoke
Height	Bespoke Guidance for specification option: Minimum by application: Bonded: 25 mm. Unbonded: 30 mm. Floating: 35 mm domestic; 40 mm commercial. Acoustic: 80 kg/m² at 40mm. Cover to conduits: 25 mm.

Uniclass	Pr_35_31_06_72 Ready-mixed self-smoothing calcium sulfate screedsPrimary
CAWS	M13/20 Proprietary self-smoothing levelling screeds M13/120 Proprietary self smoothing levelling screeds K11/295 Floating floor system

Specification data - Ready-mixed self-smoothing calcium sulfate screeds

Classification data
Form	Fluid mortar.
Mix	Manufacturer's standard.
Depth	Guidance for specification option: Insert requirements. Minimum by application: Bonded: 25 mm. Unbonded: 30 mm. Floating: 35 mm domestic, 40 mm commercial. Acoustic: 80 kg/m² at 40mm. Cover to conduits: 25 mm. Prepare the substrate in accordance with BS 8204-7:2003 using a gritted two-coat epoxy resin DPM or similar.
Third party product certification	BBA certified.
Colour	Off white.
Binder	Gypsol binder.
Density	2000 kg/m³ (dry); 2200 kg/m³ (wet).
Strength	C30—F6. Guidance for specification option: Minimum binder content 800 kg/m³. Manufacturer guidance Required strength.
Required Flow	To EN 13454-2, 230—270 mm.
Reaction to fire	Class A1fl Non-Combustible.
Working time	3 hours. Guidance for specification option: Place and finish within 3 hours of batching.
Drying time	24—48 hours (foot traffic); 7 days (loading). Guidance for specification option: Drying (50 mm depth): At 20°C and 60% RH - 28 days. Active force drying - 13 days. Can be force dried after 7 days. Independently tested and verified. Drying times vary dependent on screed depth, ambient conditions and suitability of the building envelope.
ThermalConductivity	Up to 2.3 W/m·K.

Sustainability data

Country of product manufacture	United Kingdom
Material	Calcium sulphate
A1-A3 (production stage)	Embodied carbon as defined in BS EN 15804
Normalised unit
Declared unit	8.5 kg CO₂ eq/m² Certified Guidance for specification option: Minimum: 7.5 kg/m². Manufacturer guidance Maximum.
