Armstrong Mini Instant Hot Tap With Cold Filtration - Instant and Cold Filtration Hot Tap
Verified by manufacturer 3 months ago
1833HTCP - Chrome
1833HTCP - Chrome
Mini instant hot and filtered cold.
Application
Tap suitable for use in kitchens.
Description
Near boiling water plus cold filtered water, delivered straight from a 'mini' tap.
Features and benefits:
- Open vented system.
- Digital temperature control accurate to 0.5°C.
- Multiple pre-set temperatures ranging from 75°C to 98°C.
- High quality nano filtration technology with limescale reduction.
- 2.4 Litre capacity.
- 1.5 Kw element.
- Anti-scald lock.
- Spring-back valve.
- Minimal heat loss.
- Hand crafted in the UK.
- Filtration technology.
- Ceramic disc flow control.
- Plated to a thickness that exceeds the industry standards.
- Featuring the industrial look textured handle.
General information
Color | Silver Guidance for specification option: Chrome. Grey Guidance for specification option: Nickle or Pewter. Bronze Guidance for specification option: English Bronze. Gold Guidance for specification option: Gold, Polished Brass, Satin Brass or Aged Brass. |
Finish | Chrome Polished Satin Antiqued |
Material | Brass Nickel |
Shape | Other Guidance for specification option: C-spout. |
Length | 140 mm Guidance for specification option: Projection. |
Width | 46 mm Guidance for specification option: Base diameter. |
Height | 260 mm Guidance for specification option: Overall height. |
Uniclass | |
CAWS | N11/350 Sinks, taps, traps and wastes N11/30 Sinks, taps, traps and wastes |
Specification data - Instant boiling and cold water taps
Water | Near boiling / chilled. |
Duty | |
Tank capacity | 2.4 L. |
Dimensions | 260 x 46 x 140 mm.Guidance for specification option: Overall height x base diameter x projection. |
Electrical connection | |
Power | 1.5 Kw. |
Safety features | Anti-scald lock. |
Components | Nano filtration technology.Guidance for specification option: With limescale reduction. |
WaterInletTemperatureRange | 75°C to 98°C. Guidance for specification option: Digital temperature control accurate to 0.5°C. Manufacturer guidancePre-set temperatures. |
Supply pressure | 1—5 bar (15—75 psi). Manufacturer guidanceRecommended supply pressure (min—max). |
Packaged weight | 3.8 kg. |
Spout height | 160 mm. |
Dimensions | 230 x 205 x 320 mm. |
Finish | Chrome. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Brass Nickel |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
