ASSA ABLOY Timber Single Door
Verified by manufacturer over a year ago
Single leaf timber doorset.
Application
Single leaf heavy duty timber door set for commercial, education and healthcare applications.
Description
Single leaf timber doorset.
Features and benefits:
- Solid core leaf Engineered European redwood single piece twice rebated frame (no loose stop section).
- Frame shipped to site in three pieces for site assembly.
- All flush items (hinges, lock cases, strike plates, flush bolts) are factory machined and fitted.
- Door faces are factory prepared with spindle and cylinder fixing holes where necessary.
- Fitted with complete ironmongery package which can be customized for the application; including fire rating and door finish.
General information
Color | Other Guidance for specification option: Laminate painted, RAL colours. |
Finish | Lacquered Guidance for specification option: Fully painted to RAL colour 30% gloss Veneered Guidance for specification option: Ash, Birch, European Oak, American White Oak, Maple, Steamed Beech, Walnut Primed Guidance for specification option: Primed for painting Laminated Guidance for specification option: Solid colour or woodgrain laminate Manufacturer guidanceLaminate - Either solid colour or woodgrain laminate Lacquered - Fully Painted Veneered - Crown Cut as Standard |
Material | Timber Wood |
Shape | Rectangle |
Width | 1000 mm |
Height | 2100 mm |
Warranty description | Two year |
Uniclass | |
CAWS | L20/410 Wood doorsets L20/55 Doorsets |
Specification data - Doorset systems
Doorset | |
Type | Wooden single doorsets. |
Opening width | 700 mm. 800 mm. 900 mm. 1000 mm. 1100 mm. |
Opening height | 2100 mm. 2400 mm. 2700 mm. |
Applied finish | American white oak, laminated painted, RALcolour. Guidance for specification option: Insert colour requirements. Ash veneer, laminated painted, RAL colour. Guidance for specification option: Insert colour requirements. Birch veneer, laminated painted, RAL colour. Guidance for specification option: Insert colour requirements. European oak veneer, laminated painted, RAL colour. Guidance for specification option: Insert colour requirements. Maple veneer, laminated painted, RAL colour. Guidance for specification option: Insert colour requirements. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | Revit 2015 | 3 |
 ARCHICAD | - | 2 |
 IFC | IFC2X3 | 3 |
