Automatic Sliding Guided Gate
Verified by manufacturer 29 days ago
Automatic sliding guided security gate. Security Sliding Gate- not impact rated.
Application
For heavy industrial and high-security applications like government and defence establishments, airports, warehouses and distribution centres.
Description
Automatic sliding guided gate, available up to 35 m in length. Smaller gates usually require one running guide and larger gates or gates with higher speed require two parallel guides. Designed to run on a guide installed into the roadway. It can be used for continuous or frequent use and has been installed throughout the world in varying climatic conditions.
A range of accessories options available. Operational speed is dependent on model and length; contact the manufacturer for details.
Features and benefits:
- Compliant with BS EN 13849.
- Bespoke available and larger lengths possible depending on site conditions and specifications.
General information
Color | Other |
Finish | Painted Guidance for specification option: Shot blasted, hot zinc sprayed, primed and finished with a final coat of polyurethane paint to a RAL number. This process provides a 20-year corrosion protection system for exterior, industrially non-polluted inland sites to BS 5493. |
Material | Steel |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | One year |
Uniclass | |
CAWS | Q40/45 Gates Q40/570 Gates |
Product range |
Specification data - Sliding vehicular barriers
Format | Sliding gate. |
Method of operation | Automatic.Manual. |
Barrier dimension | |
Height | Manufacturer guidanceHeight: 2400/ 5000 mm (standard/ maximum). |
Span | Manufacturer guidanceInsert requirements.
|
Barriers | |
Type | Sliding. |
Material | Steel. |
Finish as delivered | |
Worked finish | Shot blasted. |
Applied finish | Polyurethane painted.Guidance for specification option: Shot blasted, hot zinc sprayed, primed and finished with a final coat of polyurethane paint to a RAL number. This process provides a 20-year corrosion protection system for exterior, industrially non-polluted inland sites to BS 5493. |
Colour | Manufacturer guidanceAny colour to RAL; insert requirement. |
Accessories | None.100 mm diameter red/ green LED traffic light head with monitored safety circuit.Control pedestal – dual height.Control pedestal – HGV height.Control pedestal – standard height.Locking bolt.Manual release in case of power failure. |
Access control | ANPR – Automatic number plate recognition. Audio intercom. Card reader. Digital keypad. GSM intercom. |
Gate infill | Not required. Acoustic solid. Bar. Bar and weldmesh infill. Ornate. |
Top protection | Not required. 55 mm serrated edge. Barbed wire. Long blunted spikes. Palisade struts. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | 100 |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Literature
Security Gates Product Guide
