Bailey Classic Plus FR System (Cold Roof)
Verified by manufacturer 16 hours ago
High performance SBS Modified torch on solution for cold roofs.
Application
For use on flat roofs. Suited to projects where the main criteria is to meet a tight budget.
Description
High performance SBS Modified waterproofing solutions for flat roofs.
Features and benefits:
- Tested to CEN/TS 1187 at WarringtonFire, achieving a fire rating of Broof (T4).
- High quality and competitively priced range of SBS modified, high performance torch-on membranes.
- The fully modified bitumen used in their production benefits the contractor with an easy and secure product to install.
- A high bond strength and greater resistance to breakdown results in a lasting roofing.
- Weighs 5 kg/m² (3 mm-thick underlay).
- CE marked.
Also available as a warm roof system (specified separately), Classic and Classic Plus (non-fire-rated) systems are also available; consult manufacturer for details.
General information
Color | Black Guidance for specification option: Charcoal. |
Finish | Mineral |
Material | Bitumen |
Shape | Rectangle |
Length | 8000 mm |
Width | 1000 mm |
Height | 4.5 mm |
Warranty description | 20 year Guidance for specification option: Bailey Classic range of systems are covered by a simple and easy to use, self-issue guarantee. The manufacturer’s guarantee certificate comes in two parts; consult manufacturer for details. |
Uniclass | |
CAWS | J41/130 Built-up reinforced bitumen membrane cold deck roof covering J41/12 Reinforced bitumen membrane cold deck roof covering |
Product range |
Specification data - Reinforced bitumen membrane cold roof covering systems
Classification data | |
Preparation | |
Horizontal work | Bailey self-adhesive membrane primer. Guidance for specification option: 22 L cannister. |
Skirtings and vertical work | Bailey self-adhesive membrane primer. Guidance for specification option: 22 L cannister. |
Waterproof covering | |
Intermediate layer | |
Type | Bailey Universal 3 mm self-adhesive underlay. |
Attachment | Self-adhered. |
Top layer | |
Type | Bailey Classic Plus FR torch-on mineral capsheet. |
Attachment | Torch-on. |
Detail work | |
Flashings | Bailey Universal 3 mm self-adhesive underlay and Bailey Classic Plus FR torch-on mineral capsheet. |
Skirtings and upstands | Bailey Universal 3 mm self-adhesive underlay and Bailey Classic Plus FR torch-on mineral capsheet. |
Welted drips | Bailey Classic Plus FR torch-on mineral capsheet. |
Cover strips | Bailey Classic Plus FR torch-on mineral capsheet. |
Surface protection | Bailey 300 g/m² geotextile protection fleece. |
System accessories | Not required. Outlets - specified below. Guidance for specification option: See 'Outlets' for details. Bailey Sure-flow stainless steel leaf guard - F-631-L. Bailey Sure-flow stainless steel parapet leaf guard - F-632-LP. Bailey Sure-flow stainless steel cylindrical leaf guard - F-633-LC. Bailey Sure-flow stainless steel balcony leaf guard - F-634-LB. Bailey Flow-therm standard retaining unit - 25–105 mm - F-652-25/105. Bailey Flow-therm parapet leaf guard - 110 mm - F-663-110. Bailey Flow-therm parapet leaf guard - 75 mm - F-663-75. Bailey Flow-therm parapet connecting pipe - 110 mm - F-664-110. Bailey Flow-therm parapet connecting pipe - 75 mm - F-664-75. |
Outlets | Bailey Sure-flow stainless steel outlet - 40 mm (felt flange) - F-630–40. Bailey Sure-flow stainless steel outlet - 50 mm (felt flange) - F-630–50. Bailey Sure-flow stainless steel outlet - 62 mm (felt flange) - F-630–62. Bailey Sure-flow stainless steel outlet - 70 mm (felt flange) - F-630–70. Bailey Sure-flow stainless steel outlet - 75 mm (felt flange) - F-630–75. Bailey Sure-flow stainless steel outlet - 95 mm (felt flange) - F-630–95. Bailey Sure-flow stainless steel outlet - 110 mm (felt flange) - F-630–110. Bailey Sure-flow stainless steel outlet - 145 mm (felt flange) - F-630–145. Bailey Sure-flow stainless steel outlet - 160 mm(felt flange) - F-630–160. Bailey Sure-flow stainless steel parapet outlet - 110 mm (felt flange) - F-635–110. Bailey Sure-flow stainless steel parapet outlet - 50 mm (felt flange) - F-635–50. Bailey Sure-flow stainless steel parapet outlet - 75 mm (felt flange) - F-635–75. Bailey Sure-flow stainless steel roof vent (felt flange) - F-636. Bailey Flow-therm standard outlet - 110 mm (felt flange) - F-650–110. Bailey Flow-therm standard outlet - 160 mm (felt flange) - F-650–160. Bailey Flow-therm standard outlet - 75 mm (felt flange) - F-650–75. Bailey Flow-therm standard extension unit - 60 -220 mm (felt flange) - F-651-120/220. Bailey Flow-therm standard extension unit - 80–160 mm (felt flange) - F-651-80/160. Bailey Flow-therm parapet outlet - 110 mm (felt flange) - F-662-110. Bailey Flow-therm parapet outlet - 75 mm (felt flange) - F-662-75. |
Sustainability data
Contains Red List materials | No |
Material | Bitumen |
