Blackout Blind 4100 Series

Name: Blackout Blind 4100 Series
Brand: InterLace
SKU: dYfLsvp6RLwJpUTbayemZT

Verified by manufacturer 13 days ago

InterLace

Third party certifications:

CHAS
Certificate type
Constructionline
Certificate type
ISO 9001 Quality Management
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
Acclaim Accreditation
Certificate type
Constructionline Gold
Certificate type
Alcumus SafeContractor
Certificate type

The blackout blind 4100 Series system has a head box and side guide tracks which capture and retain the fabric.

Jump to:

01223 897809 Website

Application

Suitable for multiple applications, from attachment to doors through to large areas of glazing, and rooflights. Suitable for use in the most demanding environments from laboratories to schools and industrial applications

Description

The blackout blind 4100 Series system has a head box and side guide tracks which capture and retain the fabric.

Features and benefits:

Strong.
Fully cassetted blind system which is highly adaptable to different situations.

General information

Color	Black White
Finish	Powder-coated
Material	Aluminium Guidance for specification option: Extruded aluminium tubes. Fabric
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Five year Guidance for specification option: 12 months from the date of installation.

Uniclass	Pr_30_59_07_72 Roller blindsPrimary
CAWS	N10/70 Blinds N10/240 Blinds

Specification data - Roller blinds

Standards	To BS 5867-1, BS 5867-2 and BS EN 13120.
Position	Internal to glazing.
Dimensions (minimum width x depth)	Guidance for specification option: Insert requirements.
Headrail	-
Material	Aluminium extruded light-tight cassette.
Colour	White. Guidance for specification option: RAL 9016.
Blinds	-
Blackout function	Solar shading. Screening and privacy. Dim-out and blackout.
Colour	White. Guidance for specification option: White as standard. Custom RAL available.
Pattern	Cassetted roller blind.
Tube	-
Material	Extruded aluminium.
Diameter	75 mm.
Tube covers	-
Material	Aluminium extruded hembar.
Colour	White. Guidance for specification option: RAL 9016.
Operation	Manual chain operation. Manual crank operation. Electric motor operation (240 V). Manual rooflight crank operation. Electric rooflight motor operation (240 V).
Operating effort	To BS EN 13120, class 1.
Testing	Solar transmittance.
Mechanism endurance	To BS EN 13120, class 1.
Accessories	Aluminium extruded slimline side guides finished as PPC RAL 9016.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Aluminium Guidance for specification option: Extruded aluminium tubes. Fabric
Recyclability	- Manufacturer guidance Subject to fabric specified.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	100 %
