Comp-B Continuation Membrane and WebFast A2 Adhesive - Self-adhesive Continuation Membrane
Verified by manufacturer 2 months ago
Comp-B Continuation Membrane is a self-adhesive butylene membrane consisting of a butyl rubber adhesive compound specially designed and developed to be classified according to BS EN 13501-1:2018.
Application
Intended for use in the External Wall construction, as a link between the primary waterproofing system and facade DPM to create a weathertight seal for the whole building envelope.
The limited-combustibility rating of Comp-B ensures compliance for use in locations where other membranes may not be practical to install.
Description
Comp-B Continuation Membrane is a self-adhesive butylene membrane consisting of a butyl rubber adhesive compound specially designed and developed to be classified according to BS EN 13501-1:2018.
Comp-B Self-Adhesive Continuation Membrane is protected by a reinforced aluminium film and is resistant to ageing and UV-rays. It is highly adhesive, even at low temperatures, to all common building materials. It has been designed for the construction field, in particular, for those building where high performances, in terms of reaction to fire, are needed.
Features and benefits:
- Fire classified: B,s1-d0 in accordance with BS EN 13501-1:2018.
- Tear-resistant.
- Cold applied.
- Excellent adhesion at low temperatures.
- Waterproof.
- Excellent heat stability.
- Resistant to ageing and to UV-rays.
- No oil migration.
- Solvent-free.
General information
Color | Silver Grey |
Finish | Film |
Material | Aluminium Butyl |
Shape | Rectangle |
Length | 10000 mm |
Width | 1000 mm |
Height | 1 mm Guidance for specification option: Thickness. |
Uniclass | |
CAWS | J42/395 Air and vapour control layer J41/395 Air and vapour control layer J31/330 Air and vapour control layer |
Specification data - Plastics sheets
Material | Self-adhesive butylene membrane protected by a reinforced aluminium film. |
Purpose | Continuation membrane. |
Performance characteristics | |
Tensile strength (minimum) | To EN 12311-1, Machine direction (MD): 185 N/50mm. |
Tear resistance | To ATSM D 2979, probe tack: 7 N. |
Elongation to break | To EN 12311-1, Machine direction (MD): 10%. |
Water vapour resistance (minimum) | To UNI EN 1931, μ = 2.720.000. |
Fire performance | To EN 13501-1, Euroclass B,s1-d0. |
Environmental performance requirements | |
Volatile organic compounds (VOC) emissions level (maximum) | Total Volatile Organic Compound emissions (TVOC): 30 µg/m³.Guidance for specification option: To ISO 16000-6. |
Form | Reinforced. |
Physical properties | |
Colour | Grey/ silver. |
Weight (minimum) | Manufacturer's standard. |
Dimensions | |
Thickness (minimum) | 1 mm. |
Width (minimum) | 1 m. |
Roll length (minimum) | 10 m. |
Technical characteristics, other | To ASTM D 1000, 180° Peel adhesion: 20 N/cm. |
Sustainability data
Material | Aluminium Butyl |
Literature
PDS WebFast A2 Adhesive
PDS Comp-B Continuation Membrane
