D1089 Thermostatic Mixing Valve

Name: D1089 Thermostatic Mixing Valve
Brand: Crane Fluid Systems
SKU: 5BWDwnaK53YupZzU49h8kq

Verified by manufacturer 7 days ago

15 mm

A self-acting thermostatic mixing valve.

Jump to:

Application

Suitable for healthcare, schools, workplace and domestic environments.

A self-acting thermostatic mixing valve.

Features and benefits:

A self-acting Thermostatic Mixing Valves designed to blend hot and cold water, to ensure a constant, controlled safe outlet temperature.
Fulfils the ‘duty of care’ requirements against scalding.
Ideal for healthcare, schools, workplace and domestic environments.
Flat face union ensures easy removal for maintenance.
Integral strainers and check valves.
Tamper-proof adjustment.
Includes ball valves for isolation.
WRAS approved maximum operating temperature 85°C.

Uniclass	Pr_65_54_95_88 Thermostatic mixing valvesPrimary
CAWS	S90/680 Thermostatic mixing valves S90/680 Thermostatic mixing valves

Inlets/outlets diameter	15 mm.
Dimensions	200 x 108 mm. Manufacturer guidance Refer to technical datasheet for detailed dimensions.
Weight	0.82 kg.
Pressure	10 BAR. Guidance for specification option: Maximum working pressure: 10 BAR. Supply pressure imbalance dynamic: 2:1.
Operating temperature range	+30 to +50°C. Guidance for specification option: Minimum hot to mix temperature:12°C. Cold water supply temperature:5–25°C. Hot water supply temperature: 55–65°C. Temperature stability: ±2°C.
Thermostatic mixing valve	- Manufacturer guidance Crane D1089 valves have been approved for use on the following designated systems: High pressure, low pressure, Bidet (application), maximum mixed temperature 38˚C. High pressure, low pressure, Shower (application), maximum mixed temperature 41˚C. High pressure, low pressure, Wash Basin (application), maximum mixed temperature 41˚C. High pressure (TMV2), Bath (application), maximum mixed temperature 44˚C. High pressure (TMV3), Bath (application), maximum mixed temperature 44˚C.
Approvals	WRAS, NSF TMV2 and TMV3. Guidance for specification option: WRAS approved maximum operating temperature 85°C.
Materials	Chrome plated brass CW602N, POM, EPDM, Stainless steel AISI 304, ABS, PSU, Chrome Plated Brass CW607N, AI alloy, PTFE and Brass CW507L. Guidance for specification option: Body, Bonnet, Ball, Compression olive: Brass; O-Ring: EPDM; Spring; Strainer: Stainless steel; Cap: ABS, Water flow directors: PSU; T-handle: AI alloy; Ball seat: PTFE.

Material	Brass
Recyclability	Recyclable Guidance for specification option: Recycle locally, consult manufacturer for details.
Expected Life	20 year
