D2003 Automatic Air Vents & D2004 Automatic Air Vents with Shut Off Valve

Name: D2003 Automatic Air Vents & D2004 Automatic Air Vents with Shut Off Valve
Brand: Crane Fluid Systems
SKU: h5quepja2oL3HhxmncZpXa

Verified by manufacturer 7 days ago

D2003 DN10

A brass automatic air vent.

Jump to:

Application

Suitable for use where pipelines need trapped air vented.

A brass automatic air vent.

Features and benefits:

Removes inevitable potentially dangerous air trapped in system.
Simplifies the venting process.
Saves time and costs.
WRAS approved for closed circuit use only.
Conforms to design standard BS EN 1074-4.
A shut-off valve option is available in size DN15. Please specify when ordering D2004.
D2004 version with shut-off valve base allows the automatic air vent to be removed without draining the system.

Color	Bronze
Material	Brass

Uniclass	Pr_65_54_93_05 Automatic air ventsPrimary

Material	Brass EN12165 - CW617N, Brass EN 1982 - CC754S, Plastic polyamide PA6 GF30%, Plastic ACETAL, Brass EN 12164 - CW614N, Plastic PTFE, Rubber EPDM, Stainless Steel EN 10270-3 - 1.4310, Rubber NBR, Plastic polypropylene and Stainless steel AISI 302-EN 10270-3 NS. Guidance for specification option: Body, Cover, Seat, Body isolation valve: Brass; Plug, Piston, Gasket, Separating, lever, Float, Hooking system: Plastic; O-Ring, Seat gasket: Rubber; Spring: Stainless steel.
Connections	Threaded.

Inlets/outlets diameter	DN10.
Dimensions	46 x 70.5 mm. Manufacturer guidance Refer to technical datasheet for detailed dimensions.
Weight	0.146 kg.
Operating temperature range	-10 to +110°C.
Pressure	10 BAR. Guidance for specification option: Maximum discharge pressure: 7 BAR.
Approvals	WRAS approved. Guidance for specification option: For closed circuit use only.

Country of product manufacture	Europe
Material	Brass
Recyclability	Recyclable Guidance for specification option: Recycle locally, consult manufacturer for details.
Expected Life	20 year
