Dance Floors - solid hardwood flooring with floating overlay system

Verified by manufacturer 3 months ago

Junckers Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

Solid hardwood overlay sprung dance floor system.

Jump to:
+44 (0)1376 534700 Website

Application

  • For small leisure centres to large arenas.
  • Refurbishment.
  • Suitable for underfloor heating.

Description

A hardwood sprung floating floor system for dance and ballet. The system features 129 mm wide x 3700 mm long boards, manufactured from two rows of 623 mm long, graded, press dried beech staves, dovetail jointed together. The boards have precision machined tongued and grooved edges, which facilitate assembly and ensure square, secure joints. A moisture balancer is applied to the underside.


Boards are fitted together, in stagger pattern, using Junckers Steel Clips that fit into grooves machined in the back of the boards. The floor floats over a 10 or 15 mm performance foam underlay for maximum resilience. Designed for heavy wear and durability, the flooring can be laid directly over an existing flat and level subfloor or over an existing sound but substandard playing surface. Available factory finished and, if necessary, can be refinished using suitable cleaning agents and lacquers. Renovation by in-situ precision sanding and refinishing is also possible.


Features and benefits:

  • Available with 22 mm solid beech SylvaDance and 22 mm solid beech SylvaBallet boards.
  • Available in Champion, Premium, and Club grades.
  • Area-elastic according to EN 14904 class A3.
  • FSC and PEFC certified.
  • Danish Indoor Climate certified.
  • EN 15804 EPD.

General information

Color

Brown

Finish

Matt

Guidance for specification option:

Ultramatt lacquered or silkmatt lacquered.

Material

Wood

Shape

Other

Length

3700 mm

Width

129 mm

Height

22 mm

Manufacturer guidance

Thickness.

Warranty description

25 year

Uniclass

Ss_30_20_95_95 Wood floating floor systemsPrimary

CAWS

K20/20 Battened timber board floating floor

K21/111 Wood floating floor

Specification data - Wood floating floor systems

System performance

To EN 14904, class A3.

Vapour control layer

Junckers SylvaThene.

Underlay

10 mm Junckers SportsFoam.

Flooring

-

Board type

SylvaDance.

Guidance for specification option:

Two coats of a silk matt two-component polyurethane lacquer.

SylvaBallet.

Guidance for specification option:

Final sanding to grit 45 + two coats of a silk matt two-component polyurethane lacquer.

Manufacturer guidance

22 mm 2-strip solid beech. Width: 129.0 mm (±0.2 mm). Length: 3700 mm (±1.0 mm).

Perimeter flanking seal

Junckers Expansion strip.

Guidance for specification option:

12 x 12 x 1000 mm.

System accessories

None.

Nosing.

Skirting.

Stair nosing.

Appearance

Champion.

Guidance for specification option:

Where a uniformly coloured floor is needed in dedicated sports halls.

Premium.

Guidance for specification option:

For use where the main activity is competitive sport.


Club.

Guidance for specification option:

For general use.

Finish as delivered

UV light cured lacquer plus Junckers polyurethane Isolacquer - Silk matt.

Method of fixing

Clip System.

Guidance for specification option:

17 No. clips per m².

Clip size is determined on the basis of expected maximum relative humidity in the building during the year; contact manufacturer for recommendations.

Third-party certification

FSC, PEFC and Danish Indoor Climate certified, EN 15804 EPD.

Sustainability data

Contains Red List materials

No

Country of material origin

-

Manufacturer guidance

Europe.

Country of product manufacture

Denmark

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

See EPD.

Recyclability

-

Manufacturer guidance

Recyclable.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

Third party certifications

Third party certifications

EPD

EPD

EPD - Junckers solid wood two-strip flooring
