DaVinci Select Shake Starter Tiles
Verified by manufacturer 4 months ago
Aged Cedar
Aged Cedar
BBA Agrément Certificate
Certificate type
Dry-fix starter or eaves tile for all roofs.
Application
- To be used in conjunction with DaVinci Select Shake.
- Suitable for all roofs.
Description
Dry-fix starter or eaves tile for all roofs. Available in three, stocked Select Shake colours. This starter tile accessory is manufactured in the same material as the DaVinci Select Shake tiles to match the roof. DaVinci Select Shake Starter Tiles have have the same properties as the roofing shake.
Features and benefits:
- Lightweight – as low as 14 kg per square metre.
- Easy to install with pre-marked nailing guides.
- Easily cut with a fine-toothed saw or sharp utility blade.
- Starter Tiles are mechanically fixed.
- Choice of three colours to match the Select Shake tiles.
- 40-year warranty.
- Fully tested to BBA standards, including fire rating, wind, driven snow & rain, and water absorption.
- DaVinci Select Shake Starter Tiless are not made from recycled plastics but are manufactured from recyclable virgin polyethylene.
General information
Color | Brown Black |
Finish | Woodgrain |
Material | Polyethylene |
Shape | Rectangle |
Length | 350 mm |
Width | 305 mm |
Height | 6 mm |
Warranty description | 40 year |
Uniclass | |
CAWS | H60/3 Roof tiling H65/5 Roof tiling H64/10 Wood shingle/ shake roofing H64/110 Wood shingle/ shake roofing |
Specification data - Wood shakes
Form | Composite blend of virgin polyethylene, UV and thermal stabilizers and specialized fire retardant. |
Species | |
Type | Guidance for specification option: Imitates hand-split cedar shake. |
Length (minimum) | 350 mm. |
Treatment | |
Flame retardance | To EN 13501-5, BROOF(t4). |
Width | 305 mm. |
Thickness | 6 mm. |
Weight | 0.7 kg. |
Coverage | Guidance for specification option: 3.5 units cover one linear metre eaves length. |
Colour | Aged cedar. |
Sustainability data
Country of material origin | United States |
Country of product manufacture | United States |
Recyclability | Manufactured from recyclable virgin polyethylene |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % Manufacturer guidanceDaVinci Select Shake is not made from recycled plastics. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
BBA Agrément Certificate
20/5765
