Dribond SINGLEglaze® TSG50AS System - Glazed Acoustic Partition System

Name: Dribond SINGLEglaze® TSG50AS System - Glazed Acoustic Partition System
Brand: Dribond Limited
SKU: ddgGhpCyL8YWHxB5jJby5L

Verified by manufacturer 22 days ago

Dribond Limited

Acoustic glazed internal partitioning system with slim aluminium profile.

Jump to:

+44 (0) 1142 430808 Website

Application

Internal glazed partition.

Description

Acoustic glazed partition with slim profiles.

Features and benefits:

42 dB Rw sound reduction as standard upgradable.
40 mm slim depth.
50 mm narrow width.
Plant-on mullion/transom bars
Up to 5000 mm high.
Available fire rated Ei30 or Ei60 see TSG50FS
Aluminium can be powder-coated to any RAL colour.
A range of ironmongery is available to meet with the aesthetic requirements of each project.
Excellent acoustic attenuation.
Fitted with acoustic seals and acoustic dampening within the profiles.
The system incorporates fully glazed single door and double door sets utilizing a slimline aluminium frame which can be installed at full height up to 3000mm or with glass over panels, and with or glazed side screens side screens. Glass directly glazes into the door frame for flush fit appearance.

If a fire-rated system is required, see the TSG50FS system. A basic system, TSG50, is also available. Both specified separately.

General information

Color	Clear Guidance for specification option: Glazing. Silver Guidance for specification option: Aluminium - polished, linished or anodized. Other Guidance for specification option: Aluminium, powder-coated.
Finish	Powder-coated Powder-coated Guidance for specification option: Polyester powder-coating. Anodized Guidance for specification option: Etch & anodized. Stainless steel Guidance for specification option: Simulated. Wood grain Guidance for specification option: Simulated. Polished Bright Guidance for specification option: Chemically brightened. Show more
Material	Aluminium Glass
Shape	Rectangle
Length	Bespoke
Width	50 mm Guidance for specification option: Screen profile depth (base/ head/ wall).
Height	Bespoke Guidance for specification option: Maximum 5000 mm.
Warranty description	Lifetime Guidance for specification option: Please see TSG50AS data sheet for details.

Uniclass	Pr_25_71_57_60 Partition panelsPrimary
CAWS	K30/10 Relocatable partition system K30/130 Relocatable partition system

Specification data - Partition panels

Unit size	-
Thickness	50 mm. Guidance for specification option: Profile depth (screen).
Partition height (nominal)	Guidance for specification option: Insert requirements, maximum 5000 mm. Maximum applies to screens; insert details for door(s) separately below, including side screens and/or overpanels is required.
Width (nominal)	Guidance for specification option: Insert requirements, including drawing or schedule reference as required.
Deflection allowance (maximum)	-
Head	No deflection (40 x 50 mm top track head). ±25 mm deflection (50 x 50 mm top track head).
Floor	40 x 50 mm.
Verticals	40 x 50 mm.
Panel partition type	Glazed.
Framing, fixing points and joints	40 x 50 mm aluminium insulated channels with Dribond® DriJoint®/ multi-function posts. Track head as Deflection allowance above. Guidance for specification option: Channel height x depth.
Solid panels	-
Type	Not required. Alitek companel.
Finish and colour	Guidance for specification option: Omit if not applicable. Otherwise insert 'As frame', or consult manufacturer for options and insert colour requirements.
Joint treatment	-
Type	Dribond® DriJoint®.
Finish and colour	Guidance for specification option: 'As frame', or consult manufacturer for options and insert colour requirements.
Glazed panels	-
Type	Guidance for specification option: SINGLEglaze® channel; consult manufacturer's literature for options and insert glazing requirements. Manufacturer guidance Upgradeable glass options available; consult manufacturer for details. Note: this may affect performance details.
Integral blinds	Not applicable.
Additional features	Not required. 90° multi-function post.
Door arrangement	-
Type	Dribond® Alitek DR46 doorset, single door leaf. Dribond® Alitek DR46 doorset, double door leaf. Dribond® Alitek DR46 doorset, double door leaf and side screens. Dribond® Alitek DR46 doorset, double door leaf and overpanel. Dribond® Alitek DR46 doorset, double door leafs, side screens and overpanel. Solid core timber door, single leaf. Guidance for specification option: Up to 46 mm thickness; consult manufacturer for options and insert requirements. Include details for glazed side screens and/or overpanels if required. Solid core timber door, double leaf. Guidance for specification option: Up to 46 mm thickness; consult manufacturer for options and insert requirements. Include details for glazed side screens and/or overpanels if required. Manufacturer guidance Consult manufacturer for details and insert dimensions or refer to drawing/ schedule.
Locking	Guidance for specification option: Consult manufacturer for options and insert requirements.
Door frames	Aluminium. Guidance for specification option: Extruded to BS EN 755-9:2001, specification 6063 T6. Consult manufacturer for dimensions.
Door panels	-
Type	To match glazed panels. Other. Guidance for specification option: Insert glazing requirements (11–26 mm Schott PYRANOVA® multi-layer laminated fire glass). Manufacturer guidance Also comprises SiNGLEglaze channels, aluminium extruded to BS EN 755-9:2001, specification 6063 T6. Uses 75% recycled aluminium. Aluminium colour/ finish to match other components unless specified otherwise.
Vision panels	Not applicable.
Additional apertures	Guidance for specification option: Insert requirements or omit.
Ceiling	-
Joint treatment	Dribond® DriJoint®.
Perimeters, skirtings, sills	None.
Trims	Not applicable.
Hardware	Guidance for specification option: Consult manufacturer for options and insert requirements.
Seals	Dribond® Alitek ADF Acoustic door: Fitted with two acoustic seals around the perimeter as standard. Dribond® Alitek DF62 door frame: Acoustic seal to the rebate of the door frame. Guidance for specification option: Dribond® Alitek ADF fire door is a completely self-sealing system with twin fire and smoke seals around the perimeter of the door leaf and additional central intumescent fire seal which combine gives a 90-minute fire seal as standard. Dribond® Alitek DF62 fire door frame is a completely self-sealing system including around the perimeter. Within the door jamb it has intumescent fire seals which can give up to 120 minutes where specified (standard 90 minutes).
Cable management and outlets	Guidance for specification option: Internal cable management is supported. Insert requirements or omit.
Other features	Guidance for specification option: Consult manufacturer for options and insert requirements, or omit.

Finish (aluminium components)	Polyester powder-coated, colour. Guidance for specification option: Consult manufacturer for options and insert colour requirements. Polished and chemically brightened. Linished and chemically brightened. Etched and anodized. Guidance for specification option: Consult manufacturer for options and insert requirements. Manufacturer guidance Applies to all components unless specified otherwise.
Sound insulation	Partition screen: Up to 47 dB (Rw). Guidance for specification option: Standard. Consult manufacturer for details if upgradeable glass options are required.
Load	0.74 kN/m. 1.5 kN/m. 3.0 kN/m. Manufacturer guidance Nominal line load criteria of "accidental impact load" utilized. 0.36 kN/m applied as short term load at 1100 mm above FFL. Consult manufacturer's technical team for details.
Manifestation	Allowance of two rows of 50 mm dots. Allowance of two rows of 50 mm squares. Opal frost. Artwork/ custom. Guidance for specification option: Insert details. Manufacturer guidance To specifier's choice and in accordance with the requirements of approved document K. Select multiple options e.g. for door as required.
Accessories/ Special requirements	Not applicable. Sustainability: system to conform to the requirements of BREEAM. Sustainability: system to conform to the requirements of SKA. Sustainability: system to conform to the requirements of LEED. Other. Guidance for specification option: Consult manufacturer for options e.g. BIM and insert details. Manufacturer guidance Insert details as required.
Strength grade	Manufacturer's standard. Guidance for specification option: Provided independently certified evidence that all specifications variants of components comply with specified performance requirements. The frames comply with all relevant British Standard specifications, codes of practice and statutory requirements (including all revisions and amendments) as well as the guides and recommendations laid down by the relevant trade organization relating to their performance, constituent materials, method of assembly and use. All aluminium profiles are extruded to BS EN 755-9:2001, specification 6063 T6. For glass non-load bearing screens not protecting a change in adjacent floor level <380 mm. For glass load resistance criteria, see Load above. BS 5234 n/a to “all” glass partition screens. Nominal line load criteria of “accidental impact load” utilized. 0.36 kN/m applied as a short term load at 1100 mm above FFL. Glass deflection limited to L/65 or 25 mm. Maximum deflection and stress in accordance with the glass performance requirements of EN 572/ EN 12150/ EN 12543/ EN 14179 (where heat soaked). Building Regulations Part N (BS 6262) + InsStucEng publication “structural use of glass in buildings” BS 6180:2011 barriers in and about buildings for Atria or protected change in adjacent floor levels horizontal uniformly distributed line load 1100 mm above FFL (Lateral deflection limit L/65 or 25 mm, which ever is less relative to glass fixings) structural glass based on line load and attendant UDL + point load.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	4 kg CO₂ eq/unit Self declared
Recyclability	System is fully recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	72 %
