Dribond TWINglaze® TG90FS System - Fire-rated Glazed Partition System

Name: Dribond TWINglaze® TG90FS System - Fire-rated Glazed Partition System
Brand: Dribond Limited
SKU: 7C5eYcLRSKqPx83jftP5Dz

Verified by manufacturer 22 days ago

E30 (30 minutes integrity)

Dribond Limited

E30, E45,E60 or E90 fire-rated glazed internal partitioning system with an ultra-slim aluminium profile.

Jump to:

+44 (0) 1142 430808 Website

Application

Internal partition panels.

Description

E30, E60, E90 and E120 fire-rated glazed partition with an ultra-slim profile.

Through design innovation methods and years of vigorous testing and planning Dribond® has delivered a robust, fire-resisting internal partitioning system to the market which is self-sealing and upgradable from E30 by changing glass and gaskets only.

Features and benefits:

Up to 54 dB Rw sound reduction.
32 mm ultra-slim depth.
90 mm narrow width.
Mullion and transom option
Internal mullions and transoms with external plant-on bar option
Up to 3000 mm high.
Aluminium can be powder-coated, anodised, and simulated stainless steel effect.
A range of ironmongery is available to meet with the aesthetic requirements of each project.
Excellent acoustic attenuation.
The system incorporates fully glazed single door and double door sets (See data sheet DR46FS-FR108FS TG90FS door frame and door options) utilizing a slimline aluminium frame which can be installed at full height or with glass overpanels, and with or without side screens. Glass directly glazes into the door frame for flush fit appearance.

If Ei30 to Ei60 ratings are required, see the TG100FS and TSG50FS systems (specified separately).

The range also offers EW30 and EW60 options; consult manufacturer for details technical@dribond.co.uk.

General information

Color	Clear Guidance for specification option: Glazing. Silver Guidance for specification option: Aluminium - polished, linished or anodized. Other Guidance for specification option: Aluminium, powder-coated.
Finish	Powder-coated Guidance for specification option: Polyester powder-coating. Anodized Guidance for specification option: Etch & anodized. Stainless steel Guidance for specification option: Simulated. Wood grain Guidance for specification option: Simulated. Polished Bright Guidance for specification option: Chemically brightened. Show more
Material	Aluminium Glass
Shape	Rectangle
Length	Bespoke
Width	90 mm Guidance for specification option: Screen profile depth (base/ head/ wall).
Height	Bespoke Guidance for specification option: Maximum 3000 mm.
Warranty description	Lifetime Guidance for specification option: Please see data sheet for TG90FS.

Uniclass	Pr_25_71_57_60 Partition panelsPrimary
CAWS	K30/10 Relocatable partition system K30/130 Relocatable partition system

Specification data - Partition panels

Third-party certification	Warringtonfire certification available on request.
Unit size	-
Thickness	90 mm. Guidance for specification option: Profile depth (screen).
Partition height (nominal)	Guidance for specification option: Insert requirements, maximum 3000 mm. Maximum applies to panels and doors; insert details if overpanel is required.
Width (nominal)	Guidance for specification option: Insert requirements, including drawing or schedule reference as required.
Deflection allowance (maximum)	-
Head	No deflection (32 x 90 mm top track head). ±25 mm deflection (50 x 90 mm top track head).
Floor	32 x 90 mm profile.
Verticals	32 x 90 mm profile.
Panel partition type	Glazed.
Framing, fixing points and joints	32 x 90 mm aluminium insulated channels with Dribond® DriJoint®/ fire rated multi-function posts. Track head as Deflection allowance above. Guidance for specification option: Channel height x depth.
Solid panels	-
Type	Not required. Alitek companel.
Finish and colour	Guidance for specification option: Omit if not applicable. Otherwise insert 'As frame', or consult manufacturer for options and insert colour requirements.
Joint treatment	-
Type	Dribond® DriJoint®.
Finish and colour	Guidance for specification option: 'As frame', or consult manufacturer for options and insert colour requirements.
Glazed panels	-
Type	Guidance for specification option: Double glazed, TWINglaze® channels; consult manufacturer's literature for options to achieve required performance and insert requirements for fire side and non-fire side. Manufacturer guidance Upgradeable glass options available; consult manufacturer for details. Note: this may affect performance details,
Integral blinds	Required. Guidance for specification option: Consult manufacturer for details and insert requirements, 25–35 mm. Not required.
Additional features	Mullion/ transom. Guidance for specification option: Consult manufacturer for details. Doors test un-latched. Not required.
Door arrangement	-
Type	Dribond® Alitek DR46FS/ FR108FS doorset, single door leaf. Dribond® Alitek DR46FS/ FR108FS doorset, double door leaf. Dribond® Alitek DR46FS/ FR108FS doorset, double door leaf and side screens. Dribond® Alitek DR46FS/ FR108FS doorset, double door leaf and overpanel. Dribond® Alitek DR46FS/ FR108FS doorset, double door leafs, side screens and overpanel. Solid core timber door, single leaf. Guidance for specification option: Up to 46 mm thickness; consult manufacturer for options and insert requirements. Include details for glazed side screens and/or overpanels if required. Solid core timber door, double leaf. Guidance for specification option: Up to 46 mm thickness; consult manufacturer for options and insert requirements. Include details for glazed side screens and/or overpanels if required. Manufacturer guidance Insert dimensions or refer to drawing/ schedule. Maximum door frame height: 3000 mm. Maximum door leaf width x height: 1200 x 2950 mm.
Locking	Not required. Dribond® fire-rated lever latch lock with euro cylinders and lever handles. Guidance for specification option: Consult manufacturer for details. Dribond® fire-rated morticed-in mag-shear and electronic locking. Guidance for specification option: Consult manufacturer for options and insert requirements. Manufacturer guidance Options may overlap with ironmongery choices; see Hardware below.
Door frames	Aluminium, 50 x 109 mm. Guidance for specification option: Extruded to BS EN 755-9:2001, specification 6063 T6.
Door panels	-
Type	Fully glazed. Guidance for specification option: Insert glazing requirements (11–23 mm Schott PYRANOVA® multi-layer laminated fire glass). Also comprises SiNGLEglaze channels, aluminium extruded to BS EN 755-9:2001, specification 6063 T6. Solid. Guidance for specification option: Consult manufacturer for details. Manufacturer guidance Aluminium colour/ finish to match other components unless specified otherwise.
Vision panels	Not applicable.
Additional apertures	Guidance for specification option: Insert requirements or omit.
Perimeters, skirtings, sills	None.
Trims	Not applicable.
Hardware	Guidance for specification option: Consult manufacturer for options and insert requirements. Ironmongery includes Dribond® fire-rated back-to-back pull handles available in 1200, 950 or 600 mm, with push plate option. Note that the 'Dribond® fire-rated lever latch lock with euro cylinders lever handles' is specified under Locking above.
Seals	Manufacturer's standard.
Cable management and outlets	Guidance for specification option: Internal cable management is supported. Insert requirements or omit.
Other features	Guidance for specification option: Consult manufacturer for options and insert requirements, or omit.

Finish (aluminium components)	Polyester powder-coated, colour. Guidance for specification option: Consult manufacturer for options and insert colour requirements. Polished and chemically brightened. Linished and chemically brightened. Etched and anodized. Guidance for specification option: Consult manufacturer for options and insert requirements. Manufacturer guidance Applies to all components unless specified otherwise.
Fire resistance (integrity)	To BS EN 1364-1, E30.
Sound insulation	Door leaf: 34 dB (Rw). Partition screen: 47 dB (Rw). Guidance for specification option: Standard. Consult manufacturer for details if upgradeable glass options are required.
Load	0.74 kN/m. 1.5 kN/m. 3.0 kN/m. Manufacturer guidance Nominal line load criteria of "accidental impact load" utilized. 0.36 kN/m applied as short term load at 1100 mm above FFL. Consult manufacturer's technical team for details.
Manifestation	Allowance of two rows of 50 mm dots. Allowance of two rows of 50 mm squares. Opal frost. Artwork/ custom. Guidance for specification option: Insert details. Manufacturer guidance To specifier's choice and in accordance with the requirements of approved document K. Select multiple options e.g. for door as required.
Accessories/ Special requirements	Not applicable. Sustainability: system to conform to the requirements of BREEAM. Sustainability: system to conform to the requirements of SKA. Sustainability: system to conform to the requirements of LEED. Other. Guidance for specification option: Consult manufacturer for options e.g. BIM and insert details. Manufacturer guidance Insert details as required.
Strength grade	Manufacturer's standard. Guidance for specification option: Provided independently certified evidence that all specifications variants of components comply with specified performance requirements. The frames comply with all relevant British Standard specifications, codes of practice and statutory requirements (including all revisions and amendments) as well as the guides and recommendations laid down by the relevant trade organization relating to their performance, constituent materials, method of assembly and use. All aluminium profiles are extruded to BS EN 755-9:2001, specification 6063 T6. For glass non-load bearing screens not protecting a change in adjacent floor level <380 mm. For glass load resistance criteria, see Load above. BS 5234 n/a to “all” glass partition screens. Nominal line load criteria of “accidental impact load” utilized. 0.36 kN/m applied as a short term load at 1100 mm above FFL. Glass deflection limited to L/65 or 25 mm. Maximum deflection and stress in accordance with the glass performance requirements of EN 572/ EN 12150/ EN 12543/ EN 14179 (where heat soaked). Building Regulations Part N (BS 6262) + InsStucEng publication “structural use of glass in buildings” BS 6180:2011 barriers in and about buildings for Atria or protected change in adjacent floor levels horizontal uniformly distributed line load 1100 mm above FFL (Lateral deflection limit L/65 or 25 mm, which ever is less relative to glass fixings) structural glass based on line load and attendant UDL + point load.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	4 kg CO₂ eq/kg Self declared
Recyclability	System is fully recyclable
Recycled content As defined in clause 7.8 of BS EN ISO 14021	72 %
