DucoSlide Luxframe Bifold

Name: DucoSlide Luxframe Bifold
Brand: Duco Ventilation & Sun Control NV
SKU: neArFjKkB6WRjEhBv3eD4Q

Verified by manufacturer 22 days ago

Third party certifications:

Solar shading to join two panels on to each other, these can be opened and closed manually.

Jump to:

BOS

Application

Solar shading.

Solar shading to join two panels on to each other, these can be opened and closed manually.

Features and benefits:

Accentuate the façade design of any building, are built into a frame that slides away completely.
Creates a clear-cut aesthetic difference between the open and closed positions.
The manually operated panels consist of solid aluminium louvre blades or a perforated aluminium sheet for effective solar shading.
Components: Top track with wheels, bottom track with wheels, two slides, hinges and locks.

Color	- Manufacturer guidance Range of colours available in either anodized or RAL.
Finish	Anodized Powder-coated
Material	Aluminium
Warranty description	Ten year

Uniclass	Pr_30_59_09_03 Aluminium brise-soleil louvre bladesPrimary
CAWS	L10/54 Louvres L10/650 Metal louvres

Material	Aluminium. Guidance for specification option: Al Mg Si 0,5.
Finish	Anodized. Powder coated.
Colour	Anodized. RAL.

Hardware	High quality maintenance free folding hardware.
Top track	48 x 75 mm.
Bottom track	48 x 20 mm.
Panel dimensions	Guidance for specification option: Depends on windload and type of panel. Max width: 800 mm (without reinforcement optional). Max height: 3000 mm (if windload is 50%). Max 800 Pa.
Weight	40 kg. Manufacturer guidance Max weight per panel.
Panel Type	DucoSlide LuxFrame 40/40.
