ECHOSEAL ALU FR - Fire Rated Foil Tape - Aluminum Foil Tape
Verified by manufacturer today
Self-adhesive aluminium foil sealing tape. Reaction to fire class B-s2,d0. Airtight, vapour tight and waterproof.
Application
ECHOSEAL ALU FR is a fire resistant adhesive tape suitable for the airtight sealing of membrane overlaps, joints, junctions, windows and doors and around penetrations such as pipework, wiring and structural elements.
Suitable for:
- Internal and external application
- Foil faced insulation materials
- Foil faced membranes such as Partel's IZOPERM PLUS FR, EXOPERM MONO DURO 200, ECHOFOIL IZO and ECHOFOIL EXO.
Description
ECHOSEAL ALU FR fire-resistant adhesive tape is specifically designed for building applications that need a high level of fire resistance. This aluminium foil tape provides greater cohesion, adhesion, and thermal stability to the building structure due to its adhesive technology based on fire-rated properties. The tape provides optimum adhesion on all Partel aluminium-based membranes.
Features and benefits:
- Reaction to fire classification B-s2,d0 to EN 13501.
- Reaction to fire classification A2-s1,d0 for system combining the Partel IZOPERM PLUS FR membrane with max. 10% of ECHOSEAL ALU FR Tape, to EN 13501.
- Class W1 resistance to water penetration, to EN 1928.
- Water vapour diffusion tight with an Sd value >1500 m.
- Lowest VOC rating in hazardous substance test.
General information
Color | Black |
Finish | Lacquered |
Material | Aluminium Glass Fibre |
Length | 50000 mm |
Width | 75 mm |
Uniclass | |
CAWS | P10/310 Air and vapour control layer P10/60 Air and vapour control layer |
Product range |
Specification data - Aluminium foil tapes
Reaction to fire | To EN 13501-1, Class B-s2, d0.Manufacturer guidanceReaction to fire Euroclass A2-s1, d0 to EN 13501-1 for a system combining the Partel IZOPERM PLUS FR membrane with a maximum of 10% of the ECHOSEAL ALU FR Tape. |
Bond | Single-sided FR adhesive. |
Size | 0.16 x 75 mm wide. |
Material | Aluminium foil/ glass fibre. |
Tensile force | MD/CD to EN 12311-1, 800 N/50mm/ 500 N/50mm. |
Elongation | MD/CD to EN 12311-1, 4%/ 4%. |
Resistance to tearing | To EN 12310-1, 200 N/ 300 N. |
Resistance to water penetration | To EN 1928, W1. |
Peel resistance | To EN 12316-2, 7 N/25mm. |
Shear resistance of joints (to EN 12317-2) | 300 N/50mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Material | Aluminium Glass Fibre |
Expected Life | Lifetime |
Literature
ECHOSEAL ALU FR Technical Data Sheet
