Enhanced Security Doorsets - Security Door

Name: Enhanced Security Doorsets - Security Door
Brand: Principal Doorsets Ltd
SKU: dnn2xctFVZ7ufJ8tJfGqnk

Verified by manufacturer 25 days ago

General

Principal Doorsets Ltd

Third party certifications:

BM Trada
Certificate type

A range of specialist doorsets designed exclusively to provide enhanced security against intrusion and attack.Tested to PAS 24: 2016

Jump to:

+44 (0)1237 439152 Website

Application

Specialist doorsets where enhanced security against intrusion and attack is a requirement. Internal or external use.

Description

Specialist doorsets designed exclusively to provide enhanced security against intrusion and attack.

Features and benefits:

Meets PAS 24 requirements for enhanced security.
Certification by accredited third-party certification body.
Manufactured using responsibly sourced materials.
Independently tested to the recognised PAS 24:2016 standards.
Supplied as a doorset with secure ironmongery and frames.
Frame finishes can be supplied to match the door.
Full customisation of all doors and finishes (subject to certification).
Principal Doorsets are members of the Exova/ BM Trada Q Mark Scheme.
Fire rating - FD30S (44 mm) and FD60S (54 mm).
Primed, veneered, laminated, stained or factory primed.
Range of ironmongery options.
FSC certified.

General information

Color	Other Guidance for specification option: Custom colour selection.
Finish	Other Guidance for specification option: Laminated Painted Primed Stained Veneered Manufacturer guidance Various Facing options available
Material	Wood Medium density fibreboard (MDF) Particleboard Manufacturer guidance Primary door leaf construction/ facing and frame materials only.
Shape	Rectangle
Length	Bespoke Guidance for specification option: Single Doorset - Door leaf Size Between 950mm wide x 2400mm high Double Doorset - Door leaf Size Between 1050mm wide x 2400mm high
Width	Bespoke Guidance for specification option: Single Doorset - Door leaf Size Between 950mm wide x 2400mm high Double Doorset - Door leaf Size Between 1050mm wide x 2400mm high
Height	Bespoke Guidance for specification option: Single Doorset - Door leaf Size Between 950mm wide x 2400mm high Double Doorset - Door leaf Size Between 1050mm wide x 2400mm high
Warranty description	One year

Uniclass	Pr_30_59_24_97 Wood doorsetsPrimary
CAWS	L20/410 Wood doorsets L20/55 Doorsets

Specification data - Wood doorsets

Standard	Fire-rated doorset third-party-certified to PAS 24:2016.
Wood in joinery standard	To BS EN 942.
Configuration	Single-leaf, single-action - inward opening. Single door - inward and outward opening. Double door - inward and outward opening. Double-leaf, single-action. Leaf and part-leaf, single-action. Single-leaf, single-action. Double-leaf, single action. Double-leaf, single action with solid overpanel. Single leaf single action with solid overhead panels. Single leaf single action with solid side panels.
Doorset size	Guidance for specification option: Insert requirements, maximum (w x h, not including frame): 1100 x 2400 mm.
Performance	-
Fire resistance	-
Integrity	To BS EN 13501-2, E 30 minutes. To BS EN 13501-2, E 60 minutes. Not applicable.
Insulation	To BS EN 13501-2, I 30 minutes. To BS EN 13501-2, I 60 minutes. Not applicable.
Acoustic performance	To BS EN ISO 10140-2, sound reduction index Rw 37 dB minimum.
Strength and durability	To BS EN 1192, Class 4.
Thermal	Manufacturer's standard. Guidance for specification option: Consult manufacturer for details.
Intruder resistance	-
Minimum requirement	To PAS 24.
Application	Manufacturer's standard. Guidance for specification option: Consult manufacturer for details.
Conformity	Certification by accredited third-party certification body (BM TRADA).
Frame	-
Material	Hardwood.
Species	Maple. Ash. Koto. Beech. American white oak. American black walnut. Sapele.
Appearance class	J10.
Threshold	Exitex MDS 25. MDS 80/2. MDS150/2. Sealed Tight Solutions STH004. Exitex MXS/FS15. Hardwood.
Perimeter seals or inserts	Acoustic seal. Fire and smoke seal. Manufacturer guidance Consult manufacturer for details.
Finish	To match door leaf. Other. Guidance for specification option: Insert requirements.
Colour	To match door leaf. Other. Guidance for specification option: Insert requirements.
External	To match door leaf. Other. Guidance for specification option: Insert requirements.
Internal	To match door leaf. Other. Guidance for specification option: Insert requirements.
Installation fasteners	Screws. Guidance for specification option: Insert requirements to suit substrate.
Frame accessories	European redwood stops, 44 x 15 mm.
Door leaf	-
Thickness	44 mm. Guidance for specification option: Construction: Stiles and rails: None. Consult manufacturer for full details. See below for core, facings etc, 54 mm.
Core	Solid core. Guidance for specification option: Consult manufacturer for details.
Panel details	Solid. Guidance for specification option: Side panels and overpanels (where appropriate).
Facings	Manufacturer's standard.
Species	Hardwood.
Cut	Crown cut veneer. Quarter cut veneer. Rift cut veneer.
Lippings	Concealed lippings to long edges. Guidance for specification option: 8 mm thick; density: 640 kg/m³. Adhesive: Polyurethane. Exposed lippings to long edges. Hardwood to match facing veneers.
Perimeter seals	Lorient Drop Down Seal ref. LAS8001-1135.
Finish	Guidance for specification option: Consult manufacturer for details and insert requirements.
Colour	-
External	Guidance for specification option: Consult manufacturer for details and insert requirements.
Internal	As External. Other. Guidance for specification option: Insert requirements.
Glazing	-
Type	Not required. 26 mm-thick double-glazed insulating glass unit (IGU). 42 mm-thick triple-glazed insulating glass unit (IGU). Manufacturer guidance Standard glazing details: Overall size (w x h): 300 x 1000 mm. Sight size (w x h): 274 x 970 mm. Internal & external cassettes, around internal and external perimeter of glazing: Maple 24 x 14 mm (minimum). Cassette fixings: 16 No. 60 x 2 pins. Sealant: Dow Corning 785 Silicone. All insulating glass units used within a Q-Mark certified door must: Have accredited certification to EN 1279 parts 2 & 6 or accredited certification to ISO 9001 with accredited EN 1279-2 ITT & audit testing (MPI + fogging) or CE Marked to AVCP 1 with accredited EN 1279-2 ITT & audit testing (MPI + fogging). N/A to Fire Doors which must be CE Marked to AVCP 1. Have at least 1 pane of glass laminated to BS EN 356 class P1A or higher.
Manifestation	Guidance for specification option: Insert requirements or omit.
Hardware	Hardware option 1. Guidance for specification option: Hinges: 4 No. Eurospec ref. HIN1433SEC/13; Locking mechanism: Winkhaus STV-F Cobra ref. 2069 M3; Keeps: Upper: 2 No. Winkhaus ref. 2938393; lower: 1 No. Winkhaus ref. 2938393; centre: Winkhaus ref. 4929149/152; Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS. Letter plate: Royde & Tucker LP0/C with cowl. Hardware option 2. Guidance for specification option: Hinges: Halspan H30 Steel Hinges ref. HIN-BSS-103/4; Locking mechanism: Winkhaus AV2 ref. F2070/45 92/8; Keeps: Upper/lower: Winkhaus .AV2 (Ref. F24-908WR/END MV1 FX4; centre: Winkhaus ref. F24-908WR U RS; Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS. Letter plate: Royde & Tucker LP0/C with cowl. Hardware option 3. Guidance for specification option: Hinges: Cooke Brothers butt hinge, stainless steel. ref.7730; Locking mechanism: Winkhaus AV2 ref. F2070/45 92/8; Keeps: Upper/lower: Winkhaus .AV2 (Ref. F24-908WR/END MV1 FX4; centre: Winkhaus ref. F24-908WR U RS; Door closer (internal): Britton Allegion concealed closer ref. 2420 TPS. Letter plate: Royde & Tucker LP0/C with cowl. Manufacturer guidance Manufacturer's standard hardware list: Handle and cylinder specified separately (see below). Alternative cylinder/ handle combination and/or letterplate can be used subject to requirements of PAS 24:2016. Consult manufacturer for details.

Rebate size	Not applicable.
Performance	Weather rating, to BS 6375 Part 1 Exposure category 800X (on largest specimen).
Handles	Mila 115 mm lever handles ref. 050202. Winkhaus Palladio 110 mm quick fit lever handles, 44 mm.
Cylinders	Eurospec MPX6 70 mm cylinder ref. T5007. Winkhaus 70 mm cylinder ref. XR651. Manufacturer guidance Thumb-turn option: Yes.

Sustainability data

Contains Red List materials	No
Country of material origin	Europe
Country of product manufacture	United Kingdom
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	0.25 kg CO₂ eq/kg Self declared Manufacturer guidance Carbon content varies between core types. For further detail please contact manufacturer.
Recyclability	>80%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	- Manufacturer guidance Recycled content varies between core types. For further detail please contact manufacturer.

Third party certifications

BM Trada

Q-Mark Enhanced Security Door PAS 24:2016 and BS 644:2012 Timber

BM Trada

Q-Mark Fire Door Manufacture STD006
