ExtraLight Tile Kit - Lightweight Roof Tiles

Verified by manufacturer 2 months ago

Supalite Tiled Roof Systems Ltd

Lightweight roof tiling kit; a complete range of accessories to complete a roof.

Jump to:
+44 (0)1772 828060 Website

Application

Tiled roofing systems.

Specifically engineered for lightweight roof constructions. Can achieve shallow pitches.

Description

Lightweight roof tiling kit; a complete range of accessories to complete a roof.


Features and benefits:

  • Lightweight, versatile and reliable.
  • Weighing in at less than 7 kg/m², ExtraLight tiles are specifically engineered for lightweight roof constructions.
  • Easy to install.
  • Engineered to withstand the harshest weather conditions.
  • Coverage of 3.2 tiles per m².
  • Can achieve shallow pitches, providing flexibility in roof design.
  • Steel base with Zincalume® and primer to both sides, topped with a chip acrylic base, natural stone layer and an acrylic overglaze.

General information

Color

Grey

Red

Brown

Finish

Textured

Material

Steel

Acrylic

Alloy

Guidance for specification option:

Zincalume®.

Shape

Rectangle

Length

1300 mm

Width

300 mm

Height

2 mm

Warranty description

Ten year

Uniclass

Pr_25_93_72_52 Metal tilesPrimary

CAWS

H67/5 Metal roof tiling

H67/110 Metal roof tiling

Specification data - Metal tiles

Environmental performance requirements

-

Recycled content

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Finish

Textured.

Guidance for specification option:

Finished with an acrylic overglaze.

Profile

Low-profile traditional shingle.

Colour

Ember.

Guidance for specification option:

Red/ brown.

Charcoal.

Guidance for specification option:

Grey.

Walnut.

Guidance for specification option:

Brown/ red.

Manufacturer guidance

Consult manufacturer for further details.

Size

Manufacturer's standard.

Guidance for specification option:

Consult manufacturer for details.

Integral accessories

Underlay felt.
Dry ridge system.
Dry verge caps.
Barge boards.
Eaves protection system.
Fixing kits.

Guidance for specification option:

  • Underlay felt: protective felt layer installed beneath the tiles to provide an additional barrier against moisture and wind.
  • Dry ridge system: maintenance-free ridge system that provides a secure, weatherproof finish along the roof apex.
  • Dry verge caps: protective caps for the roof edges, providing a neat finish and enhanced protection against wind uplift and water ingress.
  • Barge boards: decorative and protective boards fitted along the gable ends of the roof, enhancing aesthetics and providing additional weather resistance.
  • Eaves protection system: system designed to protect the eaves and provide support for the first course of tiles, ensuring effective water runoff.
  • Fixing kits: comprehensive kit containing all necessary screws, nails, and clips for the secure installation of ExtraLight tiles and associated components.

Accessories

None.

Tile starter cleat.

Guidance for specification option:

Starter cleat ensuring the first row of tiles is securely anchored and properly aligned.

Sustainability data

Material

Steel

Acrylic

Alloy

Guidance for specification option:

Zincalume®.
