Finion Vanity Unit G08
Verified by manufacturer 8 months ago
G08100GK
G08100GK
Vanity unit with lighting, four pull-out compartments with space for two washbasins.
Application
Suitable for selected surface-mounted washbasins.
Description
Wall mounted vanity unit with lighting and four pull-out compartments. The work top is made of coloured glass and is designed for two washbasins. The carcass is available in a range of colours and finishes.
Features and benefits:
- Fastening set included.
- Provided with two wide glass drawer dividers and six narrow glass draw dividers.
- Soft closing compartments.
- Washbasins sold separately.
- Part of the Finion range.
- Push-to-open function.
General information
Color | Beige Black Blue Brown Green |
Finish | Painted Veneered |
Material | Chipboard Glass Medium density fibreboard (MDF) |
Shape | Rectangle |
Width | 1600 mm |
Uniclass | |
CAWS | N10/145 Vanity and washroom furniture |
Specification data - Vanity units
Form | Wall-mounted. |
Materials | |
Carcass | |
Frame and panels | MDF. |
Finish and colour | Anthracite matt lacquer. |
Worktop | |
Material | Glass. |
Finish and colour | White matt. |
Size (nominal) | 1600 x 603 x 501 mm. |
Integral accessories | Surface-mounted washbasins.G999 02 00 remote.Guidance for specification option: Required to control the lighting. It is not included in the scope of delivery. Only one control unit is necessary per bathroom |
Colour | Neutral white. Guidance for specification option: 2700 K Daylight white. Guidance for specification option: 6480 K |
Type | LED. Guidance for specification option: 2 x LED / 4.2 W |
Ingress protection (IP) rating | IP 44. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
 ARCHICAD | - | 1 |
 OBJ | - | 1 |
 SketchUp | - | 1 |
 3Ds Max | - | 1 |
