Fusion Glass Lockers
Verified by manufacturer 10 months ago
Aluminium lockers available in a variety of height and width combinations.
Application
- Football grounds.
- Leisure areas/ clubs.
- Schools.
Description
A hard-wearing locker system designed for both wet and dry areas. Suitable to provide a robust storage solution, it can be situated in a variety of layouts, such as on a structural back wall, as a free-standing unit, back-to-back in an island configuration, or fitted into a recess.
The unit can sit directly on a plinth, pre-installed by others, or a plywood plinth can be provided to suit. The plinth can be finished with a horizontal skirting panel or, alternatively, tiling/vinyl applied by others. Lockers can be fixed to a structural back wall to give a 'floating' appearance. Integral bench seating can be supplied to supplement the layout.
Features and benefits:
- Designed for wet and dry conditions.
- Powder Coated mild steel body.
- Standard height: 1800mm (bespoke sizes available).
- Standard widths: 300 or 400mm (bespoke sizes available).
- Standard depth: 500mm (bespoke sizes available).
- Various configurations, from 1 to 6 tier, also including z-lockers.
- Pivoted self-closing door.
- Large range of locking options.
- Can work with a variety of different plinth options.
- 3 year guarantee.
General information
Finish | Glazed |
Material | Glass |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Three year |
Uniclass | |
CAWS | N10/220 Lockers |
Specification data - Lockers
Dimensions | Manufacturer guidanceHeight: 900–2000 mm. Width: 250, 300, 400 mm. Depth: 500 mm. |
Material | Aluminium and compact grade laminate. |
Finish | Aluminium, mill-finished.Aluminium, SAA.Powder-coated, RAL. |
Fittings | Aluminium numbered faceplates.Stainless steel numbered faceplates.Satin anodized aluminium studs.Stainless steel countersunk studs.Manufacturer guidanceDoors attach to hinges with stainless steel screws into either satin anodized aluminium or stainless steel countersunk studs to the outer face of the locker door. Aluminium or stainless steel numbered faceplates, complete with pull-handle, are included. Coat hook in each locker over 900 mm high. |
Tier | One. Two. Three. Four. Five. |
Lock | Camlock. Card-operated. Coin-operated. Digital. Hasp and clasp. Manufacturer guidanceHasp-and-clasp, standard camlock, coin- or card-operated and digital locks are available. Each lock (except hasp-and-clasp) is supplied with moulded flexible PVC strap. |
Framework | Aluminium sheet bodies with rolled radius rear internal corners to reduce dirt traps, and pre-drilled holes for onsite assembly. Spring-loaded hinges, with horizontal and vertical adjustment, locate into extruded aluminium profiles. Base, top and shelf units are manufactured from high impact polycarbonate injection moulding. |
Door | 10 mm back-painted toughened glass, polished to all edges, with any required holes drilled prior to toughening. |
Skirting/ Plinth fascia | Not required. 12 mm compact grade panel, in a matching colour and polished to all edges. |
Product Reference | Fusion Glass Lockers |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
