Garnica Elegance - Plywood panels
Verified by manufacturer 6 months ago
Decorative plywood panels, available with different veneered faces.
Application
Suitable for interior applications, including furniture, decorative coverings for walls, ceilings, facades, interior partitions and dry walling.
Description
Features and benefits:
- Lightweight.
- High surface quality.
- Easy to machine, handle and transport.
- Sustainable poplar plantation core.
- FSC®-, PEFC- and CARB Phase 2-certified.
- CE-marked.
- Technical characteristics:
- Glue type (according to EN 314-2): Class 1, interior.
- Emission (according to EN 717-2): E1.
- Grades: Faces grades B/BB.
- Density: 440–490 kg/m³.
- Modulus of elasticity: 3800–5000 N/mm².
- Face screw holding: 135 kgf.
- Moisture content: 6–14%.
General information
Finish | Veneered |
Material | Plywood |
Shape | Rectangle |
Length | 2440 mm 3050 mm |
Width | 1220 mm |
Uniclass | |
CAWS | K13/150 Purpose-made K30/10 Relocatable partition system K30/130 Relocatable partition system K32/112 Fully framed panel cubicles K32/120 Panel cubicles K32/130 Privacy screens K32/140 Duct/ wall linings – panels only K32/150 Duct/ wall linings – panels and proprietary frames K32/160 Duct linings – preplumbed panels and proprietary frames N10/10 Purpose-made N10/110 Purpose-made N10/160 Shelving systems N10/30 Shelving systems N11/380 Purpose-made units N12/440 Purpose-made |
Product range |
Specification data - Visual grade general veneer plywoods
Product Reference | Elegance birch Guidance for specification option: Birch faces, soft and warm tones. Elegance cherry Guidance for specification option: Cherry faces, coppery shades. Elegance globulus Guidance for specification option: Globulus eucalyptus faces, cinnamon/ chocolate brown tones. Elegance maple Guidance for specification option: Maple faces, pale pink and marked reddish brown. Elegance red oak Guidance for specification option: Red oak faces, with toasted tones and red tints. |
Thickness | Guidance for specification option: 6–30 mm. Number of plies varies; consult manufacturer and insert requirements. |
Size (h x w) | 2440 x 1220 mm. 3050 x 1220 mm. |
