Groove Duet™ - Acoustic Panels
Verified by manufacturer 6 days ago
Groove Duet™ - 12 mm thick panel
Groove Duet™ - 12 mm thick panel
Declare
Certificate type
EPD
Certificate type
Green Tag
Certificate type
HPDC Certification
Certificate type
A range of router-cut acoustic wall panels featuring a two-tone effect.
Application
Suitable for commercial applications.
Description
Groove Duet™ is a range of router-cut acoustic wall panels featuring a two-tone effect, offering style, colour, and customisation options.
Features and benefits:
- 12 designs available.
- Ability to mix and match shades from Autex Acoustics' colour palettes.
- Transforms walls into dynamic surfaces of depth, detail and creative expression.
General information
Color | Beige Black Blue Cream Green |
Material | Polyester fibre (PET) |
Shape | Rectangle |
Length | 2400 mm 2700 mm 3600 mm |
Width | 1200 mm |
Height | 12 mm 24 mm |
Uniclass | |
CAWS | K13/170 Acoustic panel lining K13/170 Acoustic panel lining |
Specification data - Sound attenuator infill units
Classification data | |
Form | Panel. |
Rigidity | Rigid. |
Application | Wall mounting. |
Material | Polyester fibre. Guidance for specification option: 100% polyester fibre (PET). |
Acoustic performance | |
Purpose | Absorber. |
Fire performance | |
Reaction to fire | To BS EN 13501-1, Class B-s1,d0. |
Dimensions | |
Size (length x width) | 2400 x 1200 mm. 2700 x 1200 mm. 3600 x 1200 mm. Guidance for specification option: Available in select colours, minimum order quantities apply. |
Thickness (overall) | 12 mm. |
Profile | Linear. |
Edges | Square/ bevelled. Manufacturer guidanceThe panel edge is dependent on the selected surface pattern. Refer to the manufacturer’s literature for details. |
Surface pattern | Stripe V1. Oblique V2. Mesh V3. Gable V4. Radial V5. Bloc V6. Bamboo V7. Facade V8. Whisp V9. Arc V10. Refract V11. Nova V12. Manufacturer guidanceRefer to the manufacturer’s literature for details. |
Finish | Manufacturer's standard. Velour. |
Colour | Manufacturer guidanceTop colour: Vertiface® Colours Groove Duet top layer is available in the full range of Vertiface colours. Base colour: Groove Duet base panels are available in the full range of Cube colours. Consult manufacturer’s literature and insert requirements. |
Noise reduction coefficient | 0.45. |
Options | Standard groove angle (60°). Custom groove angle (30°). Custom groove angle (45°). Custom groove angle (90°). Custom groove angle. Guidance for specification option: To change groove width, angle, and depth from the standard dimensions, refer to the table in the 'Groove Duet™ Specification Guide' to configure measurements for your project, and insert requirements. |
Sustainability data
Country of material origin | New Zealand |
Country of product manufacture | United Kingdom |
Material | Polyester fibre (PET) |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 80 % |
Product certifications
Product certifications
Certification type
Declare
Declare - APA, ASL, Accent, Cube™, Frontier™, Grid Ceiling Tiles, Horizon™, Press Panels, Quietspace® Panel
EPD
Environmental Product Declaration - Cascade™, Cube™, Frontier™, Groove, Horizon™, Lanes™, Lattice, 3D Ceiling Tiles, 3D Tiles, Grid Ceiling Tiles, Quietspace® Panel, and Vicinity™
Green Tag
Global Green Tag - Cascade™, Composition®, Cove™, Cube™, Frontier™, Grid Ceiling Tiles, Groove, Horizon™, Lanes™, Lattice, Symphony®, Vicinity™, and Vertiface®
HPDC Certification
Health Product Declaration - Cube™, Cascade®, Frontier®, Horizon™, Grid Ceiling Tiles, Cove™/Loch™, Lattice, and Vicinity™
Literature
Literature type
Groove Duet Specification Guide UK
Groove Install Instructions
