GTI EL5 Connect - ESD vinyl flooring

Name: GTI EL5 Connect - ESD vinyl flooring
Brand: Gerflor Flooring UK Limited
SKU: mYve7TiWuy2gnSFryMmn5p

Verified by manufacturer 1 month ago

Electroconductive multi-layered, interlocking, looselay, heavy-duty vinyl tile designed for industrial and healthcare applications. It’s unique dovetail joint allows rapid loose-lay installation.

Jump to:

BOS

01625 428 922 Website

Application

Suitable for heavy-duty applications where an ESD solution is required such as laboratories, automatic guided vehicle areas, data room/ centres, ESD areas, cleanrooms and healthcare environments

Description

A 6 mm-thick, electroconductive multi-layered, interlocking, loose lay, heavy-duty vinyl tile reinforced with two fibreglass grids offering outstanding resistance to traffic. The Evercare™ surface treatment provides high stain resistance, easy maintenance, no wax for life and is designed for decontamination protocols. The carbon encapsulated granules throughout its full thickness, and its conductive backing and conductive surface treatment, ensure optimal and consistent conductive properties throughout its full life expectancy.

Features and benefits:

Fast and easy installation, no need to close premises.
A renovation solution – direct installation on existing floors/ problem subfloors.
Resistant to high traffic and can withstand heavy loads.
Conductive properties throughout its life expectancy.
Low static electrical propensity.
100% recyclable and contains 50% recycled content.
Also available as a GTI EL5 Cleantech version (600 x 600 mm, not interlocking), with welded joints for clean environments and watertight system requirements (specified separately).

Installation and maintenance:

Should be installed in accordance with the BS 8203:2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available.

General information

Color	Other Guidance for specification option: Please see specification data for options.
Finish	Matt
Material	Vinyl
Shape	Square
Length	635 mm
Width	635 mm
Height	6 mm
Warranty description	12 year

Uniclass	Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary
CAWS	M50/120 Interlocking resilient floor tiling M50/10 Resilient floor tiling

Product range	Tiles / ESD Flooring

Specification data - Polyvinyl chloride (PVC) tiles

Standard	To EN ISO 10582.
Use class	To EN ISO 10874, class 34-43. Guidance for specification option: Commercial, very heavy - Light industrial, heavy.
Slip potential	-
Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)	R9.
Recycled content	50%.
Size	635 x 635 mm.
Thickness	6 mm.
Colour and pattern	0350 Light Grey. 0351 Black. 0352 Grey. 0353 Beige. 0354 Blue.

Weight	9240 g/m².
Wear layer	2 mm.
ThermalConductivity	0.25 W/mk. Guidance for specification option: To BS EN 12524.
Static electricity	<2 kV. Guidance for specification option: To BS EN 1815.
Electrical resistance	5 x10^4 ≤ Rt ≤ 10^6/ Rt≤ 10^9. Guidance for specification option: To EN 1081 / IEC 61340-4-1.
Dimensional stability	≤0.25%.
Surface treatment	Evercare™.
Wear group	P. Guidance for specification option: To NF 189.
Binder	Type I. Guidance for specification option: Binder content to ISO 10582.
Accessories	Corners. Access ramp.
VOC emissions	<10 μg/m³. Guidance for specification option: TVOC after 28 days (to ISO 16000-6)

Sustainability data

Contains Red List materials	No
Material	Vinyl
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	50 % Guidance for specification option: Mimimum 50% recycled content.
