Height adjustable toilet lifter - Manual with crank handle.
Verified by manufacturer 19 days ago
Adjustable height Select T1 toilet lifter manual R8012 floor outlet
Adjustable height Select T1 toilet lifter manual R8012 floor outlet
Declare
Certificate type
WRAS
Certificate type
Manually adjustable height toilet lifters. T2 with side profile for Plus support arms, T1 without side profile. Crank handle operated.
Application
Suitable for adjusting the pan height to suit different mobile aids. Useful for wheelchair transfer or for use with mobile shower seats. R8012 and R8112 for use with floor outlet. R8022 and R8122 for use with wall outlet.
Description
A range of height adjustable toilet brackets available with manual crank handles for periodic adjustment.
Features and benefits:
- Height adjustable toilets meet the demands of both unknown users and changing requirements, perhaps of multiple users.
- Models are available for plumbing either through the floor or horizontally through the wall.
- Maximum human weight supported: 200 kg.
- Available in two colours to coordinate with modern bathrooms.
- Models with side profiles allow for the addition of PLUS support arms (specified separately).
- Easy to clean.
- Fixing kit excluded.
- Toilet seat to be ordered/ specified separately.
- CE marked.
- Five-year warranty.
General information
Color | White Grey |
Finish | Smooth |
Material | Aluminium Polystyrene |
Shape | Rectangle |
Length | 1230 mm Manufacturer guidanceMinimum. |
Width | 815 mm Guidance for specification option: TL2. 555 mm Guidance for specification option: TL1. |
Height | 215 mm Manufacturer guidanceDepth. |
Warranty description | Five year |
Uniclass | |
CAWS | N13/300 WCs and cisterns |
Specification data - WC suites
Form | Back to wall cistern. |
Materials | |
Body | Aluminium and polystyrene (PS). |
Finish and colour | White.Anthracite. |
Sizes | |
Cistern capacity | 3/6 L dual flush. |
Pan height | 425–725 mm. |
Integral accessories | Crank handle. |
Accessories | Wall-hung pan R2098 540 mm. Wall-hung pan R2099 700 mm. |
Operation | Manually, height adjustable. Guidance for specification option: Adjusted by means of a crank handle, they are recommended for periodic alteration. Can be positioned on either side of the lifter without the need for tools, and can also be adjusted via an electric drill. |
Height adjustment range | 300 mm, from 425–725 mm. |
Dimensions | 1230 x 555 x 215 mm. Manufacturer guidanceLength x width x height. |
Noise | 48 dB. |
NominalPowerConsumption | 70 W (at maximum load) and 2 W (at standby). |
Nominal voltage | 230 V. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Denmark |
Country of product manufacture | Denmark |
Material | Aluminium Polystyrene |
Recyclability | Pressalit is a member of the Veolia WEEE Producer Compliance Scheme with the Weee Producer Registration Number: WEE/MM9866AA |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Third party certifications
Declare
EU declaration of conformity R801
Declare
DVGA for manual toilet lifter
WRAS
WRAS RT623 tap
