Hudevad Novus - Radiator Bench

Name: Hudevad Novus - Radiator Bench
Brand: Hudevad Radiator Design A/S
SKU: abS8RQw8BKTPWafo7ZPAG9

Verified by manufacturer 6 months ago

Type 70 Radiator Bench

Hudevad Radiator Design A/S

Floor-mounted bench radiator with integrated legs.

Jump to:

+44 (0)24 7688 1200 Website

Application

Suitable for use in many public spaces, such as hospitals, schools and offices as well as private homes.

Description

The Novus Bench radiator is suitable for use in many public spaces, such as hospitals, schools and offices as well as private homes. Its symmetrical lines and functional shapes without convectors make cleaning easy.

Placed in front of windows, Novus is suitable as protection against cold drafts.

Features and benefits:

Pre-treatment by degreasing and steel phosphating in accordance with DIN EN 442 and DIN EN 12476.
Powder coated in accordance with DIN 55900, EN 442.
Max operating pressure 6 bar according to EN 442.
Panels: profiled steel tubes 70 x 11 x 1.8 mm.
Distance between panels are 20 mm.

General information

Color	White Guidance for specification option: White RAL 9016 70% Gloss. Other
Finish	Powder-coated
Material	Steel
Shape	Rectangle
Length	1000 mm 1100 mm 1200 mm 1400 mm 1500 mm 1600 mm 1800 mm 2000 mm 2200 mm 2400 mm 2500 mm 2600 mm 2800 mm Show more
Width	197 mm 259 mm 321 mm
Height	190 mm 400 mm
Warranty description	Ten year

Uniclass	Pr_70_60_36_73 RadiatorsPrimary Pr_40_30_29_84 Street and site benches
CAWS	T90/465 Radiators Q50/220 Benches T90/465 Radiators Q50/33 Benches

Specification data - Radiators

Standards	To BS EN 442-1 and BS EN 442-2.
Radiator type	Bench.
Output	Guidance for specification option: Consult manufacturer and insert requirements.
Finish	Powder-coated. Guidance for specification option: In accordance with DIN 55900, EN 442.
Connections	Guidance for specification option: Consult manufacturer and insert requirements. Manufacturer guidance All connections 1/2” standard.
Accessories	Not required. Leather cushions. Guidance for specification option: L: 420 x W: 270 x H: 10 mm. In the colours cognac, dark brown and black.

Panels	Profiled steel tubes. Guidance for specification option: 70 x 11 x 1.8 mm.
Panels	Seven.
Colour	White RAL 9016, gloss 70. Guidance for specification option: Standard. Other. Guidance for specification option: Can be painted in other colours. Insert requirements.
TestPressure	8 bar.
Operating pressure (maximum)	6 bar.
Operating temperature	110°C.
Height	190 mm. 400 mm.
Depth	197 mm.
Length	1000 mm. 1100 mm. 1200 mm. 1400 mm. 1500 mm. 1600 mm. 1800 mm. 2000 mm. 2200 mm. 2400 mm. 2500 mm. 2600 mm. 2800 mm. Show more
Tapping configuration	Type code 50. Guidance for specification option: Tapping type: E/F, no valve. Type code 52. Guidance for specification option: Tapping type: FF, right. Type code 53. Guidance for specification option: Tapping type: EE, left.

Sustainability data

Contains Red List materials	No
Country of material origin	Italy
Country of product manufacture	Latvia
Recyclability	Yes
Recycled content As defined in clause 7.8 of BS EN ISO 14021	100 %
