illbruck TP600 NG Compriband Impregnated Sealing Tape - Impregnated Foam Tape
Verified by manufacturer 2 days ago
BBA Agrément Certificate
Certificate type
BBA Agrément Certificate
Certificate type
An impregnated joint sealing tape for use in a wide variety of movement joints, including window perimeter seals and other applications.
Application
TP600 NG is an impregnated joint sealing tape for use in a wide variety of movement joints, including window perimeter seals and other applications. It satisfies most requirements as an external weather seal in building and civil engineering applications.
Description
TP600 NG is a soft and flexible open-cell polyurethane foam, impregnated with an acrylic-based, UV-stabilised resin. The resin is water repellent and contains a fire retardant. It is supplied as pre-compressed rolls with a self-adhesive side to aid initial location.
Weather-tight against the most severe combinations of wind and rain, it satisfies most expectations as an external weather seal for window perimeter seals and in building and civil engineering applications.
With full BBA certification, the product has been extensively tested and has a proven reputation across both the UK and Europe. BBA Certificate N° 12/4891 Product Sheet 6 and 12/4891 Product Sheet 1 as part of the illbruck i3 system.
Features and benefits:
- 15-year performance guarantee.
- Weather seal for wind-driven rain.
- Breathable – for vapour diffusion.
- Continually expands and contracts to accommodate movement whilst still sealing the joints.
- Thermal and acoustic insulation.
- Meets CWCT test for site water tightness (TN41).
For Technical Data Sheets and Safety Data Sheets, please refer to the illbruck website Download Centre.
General information
Color | Grey Black |
Material | Polyurethane |
Length | Manufacturer guidanceConsult manufacturer for details. |
Width | Manufacturer guidanceConsult manufacturer for details. |
Warranty description | 15 year Guidance for specification option: Any product which has been applied (a) in accordance with Tremco CPG UK Ltd written instructions and (b) in any applications recommended by Tremco CPG UK Ltd, but which is proved to be defective, will be replaced free of charge. In addition, illmod TP600 has a separate 15 year performance guarantee. |
Uniclass | |
CAWS | L20/820 Sealant joints L20/80 Sealant joints L10/810 Sealant joints L10/75 Sealant joints |
Product range |
Specification data - Resin-impregnated precompressed foam sealing strips
Classification data | |
Materials | |
Foam | Polyurethane (PU). Guidance for specification option: Impregnated open cell PU foam tape. |
ExposureClass | To DIN 18542, Class BG1. |
ThermalConductivity | To DIN 52612 ~ λ10 <0.48 W/m/K. |
Vapour resistivity | To DIN 52615 ~ µ <100 . |
Air permeability | To DIN 18542 α <1.m³. |
Application temperature | -5°C to +30°C. |
Service temperature | -30°C to +90°C. |
Shelf life | Two years when stored in its original unopened container. |
Storage | Store horizontally in original carton between 1° and 25° in dry conditions away from direct sunlight. |
Standard | To DIN 4102 B1, self-extinguishing, P-NDS 04-229. |
Colour | Anthracite. Grey. |
Execution | Manufacturer guidanceIn strict accordance with the manufacturers Technical Data Sheet. Illmod TP600 must be seated between two parallel solid surfaces. The joint depth must be at least equal to the width of tape selected. Do not exceed the stated sealing tolerance for any given size. Consideration for the residual thickness of the tape must be given when using in expansion /deflection joints, the tape cannot be compressed below its' pre-compressed state. |
Accessories | Cutting shears. Skewer. Putty knife. |
Third-party certification | British Board of Agrément. Guidance for specification option: Cert. 96/3309. |
Reaction to fire | To BS EN 13501-1, Class B-s1,d0. |
Sustainability data
Material | Polyurethane |
BIM objects
This BIM object has been authored to meet the requirements of the
Find out more about the
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Product certifications
BBA Agrément Certificate
BBA Certificate Full i3 System
BBA Agrément Certificate
TP600 BBA Certificate
Literature
TP600 Declaration of Performance
