INTRAgrille XT - Double Module - Entrance Matting

Name: INTRAgrille XT - Double Module - Entrance Matting
Brand: INTRAsystems
SKU: eYCPS6v1DJC2B84wd8ueVH

Verified by manufacturer 3 months ago

INTRAsystems

Stainless steel scraper bars and double-width fibre inserts deliver maximum moisture absorption with a luxury finish.

Jump to:

BOS

+44 (0)1425 472000 Website

Application

Suitable for high traffic environments in commercial offices and public buildings.
For internal use – choose from Elite polyamide, Premier polyamide, and polypropylene inserts.
Can be used in conjunction with wheelchairs and shopping trolleys, and the material is heel-proof.

Description

A superb example of engineered stainless steel. This versatile product offers the performance advantage of double width fibre for optimum moisture absorption.

Features and benefits:

DDA-compliant, suitable for wheelchair access.
Heel proof open construction - allows dirt and moisture to fall through into the matwell below.
Optimum dirt and moisture removal.
Edge trim material of stainless steel with INTRAlux Elite, Ultimate and Select fibre inserts entrance matting material.
Suitable for a wide range of fibre inserts.

Installation:

Can be installed into suitable recessed matwell area (surface level with adjoining floor covering), or surface mounted with the use of ramped edging.

General information

Color	Black Grey Red Blue Brown Purple Show more
Finish	Stainless steel
Material	Stainless steel Guidance for specification option: Stainless steel grade 316.
Shape	Rectangle Other Guidance for specification option: Can be cut to any matwell shape/size. Contact manufacturer for details.
Length	Bespoke Guidance for specification option: Cut to size requirements. Contact manufacturer for details.
Width	Bespoke Guidance for specification option: Cut to size requirements. Contact manufacturer for details.
Height	15 mm Manufacturer guidance Depth.
Warranty description	Ten year

Uniclass	Pr_25_71_42_70 Raised access floor panelsPrimary Pr_35_57_11_26 Entrance mats
CAWS	N10/300 Entrance matting L30/30 Proprietary stairs L30/45 Ramps/ walkways L30/310 Proprietary stairs Q10/180 Drainage channel systems with gratings L30/460 Walkways P31/370 Access covers/ gratings

Product range	Entrance Matting Systems

Specification data - Raised access floor panels

Classification data
Casing	-
Material	Stainless steel grade 316.
Panel size	- Manufacturer guidance Bespoke. Insert requirements.
Weight (maximum)	23.4 kg/m².
Plate width	57 mm.
Inserts	INTRAlux Elite polyamide fibre. INTRAlux Ultimate polyamide fibre. INTRAlux Select polyamide fibre
Mat well frame	INTS019.
Colour	602 Blue. 604 Coco. 605 Brown. 606 Grey. 607 Anthracite. 608 Black. 609 Purple. 601 Red. 610 Turquoise. 443 Anthracite. 451 Grey. 130 Black. 138 Slate Grey. 50 Black. 207 Grey. 208 Black.
Depth	15 mm.
Construction	Open.
