JUTA GP®H 0.6mm

Verified by manufacturer 2 months ago

Juta UK Ltd

Mono-layer, linear high-density polyethylene membrane.

Jump to:
+44 (0)1772 754177 Website

Application

Suitable for use in various demanding geomembrane applications such as SUDS, root barrier, waterproofing and radon protection and permeable paving.

Description

GP® H 0.6 mm - is a mono layer, high-density polyethylene membrane specifically designed and manufactured to perform as a robust waterproofing barrier protection system, which is suitable for use in various demanding geomembrane applications such as damp/waterproofing and radon protection.


GP® H 0.6 mm also provides resistance to ground borne gasses such as methane and carbon dioxide.


GP® H 0.6 mm is a fully weldable liner and is CE marked for use in the following application areas: EN13967 (A/T).


GP® H 0.6 mm provides resistance to root penetration from invasive species, including (but not limited too): Japanese Knotweed, Bamboo, Mustard Seed, Meadow Grass, Ivy, Hybrid Poplars, Willow, Elm, Maple, Mare’s tail, ground creeping plants, edible plants and aquatic plants.

General information

Color

Black

Finish

Smooth

Material

High density polyethylene (HDPE)

Guidance for specification option:

High-density polyethylene (HDPE).

Mono-layer, linear high-density polyethylene membrane.

Shape

Other

Length

50000 mm

Width

2500 mm

Height

0.6 mm

Warranty description

60 year

Uniclass

Pr_25_57_65_60 Plastics sheetsPrimary

CAWS

J44/115 Geomembrane lining

J44/110 Geomembrane lining

J40/145 Loose-laid weldable polyethylene gas-retardant membranes

J40/140 Loose-laid plastics or rubber sheet gas-retardant membranes

J40/35 Loose-laid plastics or rubber gas-retardant membranes

D20/550 Geotextile sheet

D20/58 Geotextile sheet

Specification data - Plastics sheets

Material

High-density polyethylene (HDPE).

Purpose

Waterproof layer.

Standard

To EN 14150, EN 1931, EN 1928, EN 12730-B, EN 12311-2(A), EN 12310-1, EN 12691 (A), EN 12317-2, EN 1269, EN 1847.

Performance characteristics

-

Tensile strength (minimum)

500 N/50mm.

Tear resistance

MD:450 N; CD: 500 N.

Resistant to underground gases

Radon.

Physical properties

-

Colour

Black.

Dimensions

-

Thickness (minimum)

0.6 mm.

Width (minimum)

2.5 m

5.1 m

Roll length (minimum)

50 m.

100 m.

Product Reference

HDPE 06

Sustainability data

Contains Red List materials

No

Country of material origin

Czechia

Country of product manufacture

Czechia

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

2.20 kg CO₂ eq/kg

Self declared

Recyclability

Fully Recyclable

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %
