Koster NB1 Grey Cementitious Coating.
Verified by manufacturer 5 days ago
BBA Agrément Certificate
Certificate type
EPD
Certificate type
Internal Type A Waterproofing coating to BS 8102 2022. A mineral based crystalline coating for the waterproofing below ground structures against both negative and positive side pressure.
Application
Koster NB1 Grey is suitable for use in, but not limited to the following areas:
- Application to any mineral surface i.e., concrete, pre-cast, block, brick, masonry, stone, etc.
- Waterproofing against ground moisture, non-pressurized and pressurized water.
- For both new build and refurbishment projects.
- As a part of a Type A waterproofing system, as per BS 8102 2022.
- In the refurbishment of civil structures such as tanks, pipes, silos, manholes, tunnels, bridges and drinking water tanks.
- For the waterproofing of pile heads and through construction joints.
Description
Koster NB1 Grey is a mineral coating which contains crystallising and capillary-plugging agents.
Uniquely, It can applied to any mineral substrate not just concrete. Many similar materials can only be applied to a new concrete as they require the free lime to activate the waterproofing coating.
Features and Benefits:
- Resistant to 13 bar water pressure (130m below ground).
- Excellent chemical and sulfate resistance.
- Extremely high resistance to pressure and abrasion.
- Self healing over micro cracks.
- Flexible Type A waterproofing coating.
- For negative side and positive side waterproofing.
- Open to vapour diffusion.
- No VOCs or corrosive ingredients.
- Can be used on all mineral substrates.
- Easy to apply, seamless application.
- Inhibits salt movement in the substrate when used as a system together with Koster Polysil TG 500.
For further technical advice and project specific guidance, please contact technical@kosteruk.com.
General information
Color | Grey |
Finish | Brushed Smooth |
Material | Cement Manufacturer guidanceCementitious slurry |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | J10/130 Proprietary crystallization active mortar |
Product range |
Specification data - Crystallization active slurry mortars
Third-party product certification | BBA certificate. |
Coverage | 2–4 kg/m². |
Setting time | Resistant to foot traffic after one day; Full cure after two weeks (approximately). |
CompressiveStrength | > 30 N/mm² at 28 days. |
Tensile Adhesion | ≥ 0.5 MPa. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Manufacturing plant location | |
Material | Cement Manufacturer guidanceCementitious slurry |
Recyclability | No |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Expected Life | 120 year |
