Lansdowne | Concrete Facing Brick
Verified by manufacturer 3 months ago
EPD
Certificate type
Concrete facing brick.
Application
Suitable for above ground main external wall construction and boundary walls regardless of exposure conditions.
Description
Concrete facing brick available in nine colours, including subtle colour blends that create a warm, natural appearance and complement the paving range.
Features and benefits:
- BREEAM rating A+, in accordance with the Green Guide to Specification.
General information
Color | Red Guidance for specification option: Cottage Red. Moorland. Gold Guidance for specification option: Autumn Gold. Meadow Gold. Multi Buff. Other Guidance for specification option: Burren. Charcoal. Heather. Slate. Grey |
Material | Concrete |
Shape | Rectangle |
Length | 215 mm |
Width | 100 mm |
Height | 65 mm |
Uniclass | |
CAWS | F10/215 Concrete facing brickwork F10/5 Facing brickwork |
Product range |
Specification data - Aggregate concrete bricks
Standard | To BS EN 771-3.Manufacturer guidanceInstalled to BS 5628-3. |
Brick description | Facing brick. |
Compressive strength | |
Mean value | 22 N/mm². |
Category | >22 N/mm². |
Freeze-thaw resistance | F2 (severe exposure). |
Thermal conductivity | Protected 1.59 W/m·K; exposed 1.70 W/m·K. |
Thermal resistance | Manufacturer's standard.Guidance for specification option: Consult manufacturer for details. |
Recycled content | Not less than 10%. |
Work sizes (length x width x height) | 215 x 100 x 65 mm. |
Tolerance category | Category D1. |
Density | |
Gross dry density | 1930 kg/m³. |
Reaction to fire | A1. |
Water absorption by capillarity | 2 g/m²/s. |
Efflorescence | Minimum 12 hour vapour curing to significantly reduce the possibility of efflorescence. |
Shrinkage | 0.44 mm/m. |
Weight | 2.7 kg per brick (average). |
Mortars and expansion Joints | To BS 5628-3:2005. |
Bed reinforcement | To BS 5628-3:2005. |
EnergyUsed | 100%. |
WaterUsed | 100%. |
BREEAM rating | A+, in accordance with the Green Guide to Specification. |
Colour | Autumn gold. Burren. Charcoal. Cottage red. Heather. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Concrete |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 0.31 kg CO₂ eq/m² |
Recyclability | 100% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer guidanceNot less than 10%. |
Third party certifications
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Third party certifications
EPD
Environmental Product Declaration (EPD)- Hydropave Tegula 240, Hydropave Tegula Duo 60mm, Retro 60mm, Tegula , Tegula Setts, Tegula Trio, Kingston 215x100x65mm, Lansdowne 215x100x65mm, Kerbstone
