Megaflo Eco Unvented Cylinders - Direct and Indirect Hot Water Cylinders

Verified by manufacturer 2 days ago

Indirect - 70i

BAXI HEATING UK LIMITED Variant:

High performance water heating for invigorating showers and faster-filling baths.

Jump to:
0330 678 0140 Website

Application

Suitable for domestic and light commercial applications.

Description

Megaflo Eco provides exceptionally high levels of comfort and hot water performance, providing hot water for fast filling baths and powerful showers. As the Megaflo Eco is connected directly to the mains cold water supply, hot water is readily available at all outlets and at mains pressure. It can be positioned in almost any location without detriment to the performance and is simple to install with virtually no maintenance required. The added feature of accommodating any expansion within the Megaflo Eco itself means that no unsightly expansion vessels are on show, so a neat, tidy and compact installation is guaranteed.

Features and benefits:

  • Robust and safe handle for improved manoeuvrability
  • Improved re-heat time.
  • 60 mm of CFC/ HCFC-free injected foam for the best possible heat retention and energy efficiency.
  • High performance 'coil-in-coil' heat exchanger in indirect models for exceptionally fast recovery times.
  • 'L' shaped immersion heater maximises the volume of hot water available in direct models.
  • Titanium electric heating elements on direct models for extra long-life.
  • KIWA-approved and Nemko (N-Mark) certified product.

General information

Color

White

Finish

Coated

Material

Stainless steel

Steel

Extruded polystyrene (XPS)

Shape

Circle

Width

579 mm

Height

802 mm

1102 mm

1229 mm

1384 mm

1486 mm

Show more

Uniclass

Pr_60_50_20_42 Indirectly heated unvented hot water storage cylindersPrimary

CAWS

S90/410 Indirectly heated unvented hot water storage

SKU Code

95050461

Specification data - Indirectly heated unvented hot water storage cylinders

Classification data

Standard

To BS EN 12897.

Third-party certification

KIWA-approved and Nemko (N-Mark) certified.

Capacity

70 L.

Pressure

0.3 MPa (3 bar).

Guidance for specification option:

  • Maximum supply pressure to incoming mains cold water combination valve (supplied): 1.6 MPa (16 bar).
  • Minimum recommended supply pressure and flow rate: 0.15 MPa (1.5 bar) – 20 L/min.

Safety equipment

Provide energy cut-out device, temperature relief valve, pressure-reducing valve and backflow prevention in accordance with BS EN 12897.

Accessories

Immersion heater.

Guidance for specification option:

Element rating (at 240 V/kW): 1 x 3.

Integral accessories

Coil-in-coil heat exchanger.

Flow rate (maximum)

76 L/min.

Manufacturer guidance

Maximum flow at 3 bar.

Cylinder

Duplex stainless steel.

Insulation

60 mm CFC/HCFC-free injected expanded polystyrene foam.

Height

802 mm.

Diameter

579 mm.

Weight

25 kg (empty); 125 kg (full).

Environmental performance

ErP rating: B.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Material

Stainless steel
Steel
Extruded polystyrene (XPS)

Recyclability

-

Manufacturer guidance

The cylinders are largely recyclable:

  • Stainless steel components can be recovered.
  • Polyurethane insulation and plastic parts may require specialist recycling.
  • Manufacturer guidance supports responsible disposal.

Expected Life

30 year

Literature

Megaflo Eco Indirect - Specification Guide

Megaflo Eco Indirect - Specification Guide

Megaflo Eco Direct - Specification Guide

Megaflo Eco Direct - Specification Guide
