Nu-Resistant Lockers

Verified by manufacturer over a year ago

Nu-Style Products Ltd

Designed specifically to perform where in continuous use, high traffic, high humidity, and aggressive environments.

Jump to:
BOS
+44 (0)1224 823000 Website

Application

  • Toilets, schools, nursery, offices, hospitals, airports, leisure centres.
  • Can be manufactured in fire resistant material for use in offshore accommodation blocks; consult manufacturer for details.

Description

High-traffic, continuous use compact-grade laminate lockers for use in high humidity areas and aggressive environments.


Features and benefits:

  • No framing required.
  • Supplied fully assembled.
  • Available in a wide range of colours.
  • Choice of mechanical and electronic locking options available; consult manufacturer and insert requirements.

General information

Color

-

Manufacturer guidance

See 'Options' below and insert requirements.

Material

Solid-grade laminate (SGL)

Uniclass

Pr_40_30_87_48 LockersPrimary

CAWS

N10/220 Lockers

Specification data - Lockers

Dimensions

300 x 1800 x 300 mm.

Guidance for specification option:

Width x height x depth.

500 x 1800 x 600 mm.

Guidance for specification option:

Width x height x depth.

Material

6 mm-thick solid-grade laminate (SGL).

Guidance for specification option:

Carcass, with dressed edges.

12 mm-thick solid-grade laminate (SGL).

Guidance for specification option:

Doors and shelves.

Colour

-

Manufacturer guidance

  • Available in Formica or Polyrey Washroom Collection as standard; consult literature for details.
  • Also available in Arpa Athlon UK or Abet Cubicle Collection; consult manufacturer for details.

Fittings

Hinges.

Guidance for specification option:

Standard, integrated three-part sprung hinge with stainless steel spring.

Product Reference

Nu-Resistant Lockers

Accessories

Not required.

Coat hooks.

Coat rails.

Shelves.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2017

1

IFC
-

1
