Nuway Connect Open - Entrance mat
Verified by manufacturer 4 months ago
Certificate of Conformity
Certificate type
Nuway connect is a very versatile roll-up single sided entrance system that is easy to shape on site, making it ideal for awkwardly shaped entrances.
Application
Suitable for entrance areas subject to high levels of pedestrian traffic and where soiling has a high moisture or dust content.
Description
With a wide choice of inserts, Nuway Connect can be adapted to suit individual requirements. Bristle inserts can be used for exterior and interior entrances to remove coarse dirt. Rubber inserts can also be used for exterior and interior entrances.
The open construction means dirt is collected in the matwell rather than on the surface for easier cleaning. The mat can also be easily rolled up for cleaning.
Nuway connect is a very versatile roll-up single sided entrance system that is easy to shape on site, making it ideal for awkwardly shaped entrances.
Connect is also available in a wide choice of heights from 10, 17 and 22 mm and in open or closed constructions.
To discuss your specific entrance system requirements and configuration, please contact Forbo directly for a full technical evaluation and design.
General information
Color | Black Grey Red |
Finish | Anodized |
Material | Rubber Aluminium Manufacturer guidanceCarpet |
Length | Bespoke |
Width | Bespoke |
Height | 10 mm |
Warranty description | Five year Guidance for specification option: 10 years if installed by a FESSI, Forbo Entrance System Specialist Installer |
Uniclass | |
CAWS | N10/300 Entrance matting |
Product range |
Specification data - Entrance mats
Arrangement | Loose lay external or internal. |
Material | Aluminium matting with textile or rubber inserts. |
Colour | Not required.4701 Coral Classic anthracite.4730 Coral Classic raven black.4750 Coral Classic warm black.4753 Coral Classic bright red.Ultragrip safety rubber standard colour.Four row bristle black. |
Integral accessories | Not required.Existing.AMF 253.AMF 346.AMF 506.ARF 50.ARF 70. |
Type | Open. |
Maximum width per module | 3000 mm. |
Dynamic load (kg) 2 wheels, 80mm, 20,000 passes | Texile only = 200 kg. Textile and bristle = 50 kg. Bristle only = 50 kg. Bristle and rubber = 50 kg. |
Fire behaviour (to BS EN ISO 9239-1) | Bfl-S1. |
Thickness | 10 mm. 17 mm. 22 mm. |
Maximum static load (Kg/ cm2) | Textile only = 200 kg. Textile and bristle = 50 kg. Bristle only = 50 kg. Bristle and rubber = 50 kg. |
Sustainability data
Country of material origin | United Kingdom |
Material | Rubber Aluminium Manufacturer guidanceCarpet |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | Revit 2015 | 1 |
Third party certifications
Certificate of Conformity
SA8000 Management System Certification Certificate
