Omega Flow Permeable Block Paving

Name: Omega Flow Permeable Block Paving
Brand: Brett Landscaping
SKU: qXNmCTn7Km8ZURw9FFtyJM

Verified by manufacturer 4 months ago

60 mm Single size packs

A classic, rectangular, permeable concrete block paving unit, with excellent permeability for achieving SuDS and surface water drainage considerations.

Jump to:

+44 (0)345 60 80 570 Website

Application

Domestic and commercial use: hardstanding for vehicular and pedestrian pavements including footpaths, cycle tracks, driveways, adoptable highways, commercial pavements, heavy duty pavements, roof top and balcony applications.

Description

Omega Flow concrete block paving has a contemporary, clean style which will complement most environments and has been designed for use in either hand or machine lay applications. Omega Flow concrete block paving also comes in thicknesses of up to 80 mm meaning that it can be tailored to suit almost any trafficking application.

Omega Flow paving blocks come with a number of complimentary products including marker blocks, kerbs as well as an impermeable paving range which includes pencil edge blocks and Bishops Hat edging blocks.

When tested to DD 229: 1996 for Surface Permeability Omega Flow achieved 4265 mm/h.

Standards:

Brett Landscaping operate a number of independently audited management systems:

BS EN ISO 9001: 2008 Quality Management System.
BS EN ISO 14001: 2004 Environmental Management System.
OHSAS 18001: 2007 Health and Safety Management System.
BES 6001 Responsible Sourcing of Construction Products.

General information

Color	Gold Brown Black
Finish	Smooth
Material	Concrete Guidance for specification option: Precast (semi-dry-pressed and vibrated).
Shape	Rectangle
Length	215 mm
Width	115 mm
Height	60 mm 80 mm
Warranty description	- Manufacturer guidance Statutory Rights - Technical Support.

Uniclass	Pr_25_93_60_17 Concrete paving blocksPrimary
CAWS	Q24/115 Permeable concrete block paving – total infiltration Q24/117 Permeable concrete block paving – partial infiltration Q24/119 Permeable concrete block paving – no infiltration Q24/12 Permeable concrete block paving

Product range	Omega

Specification data - Concrete paving blocks

Standard	To BS EN 1338: 2003.
Physical properties	-
Colour	Autumn Gold. Brindle. Burnt Oak. Charcoal. Natural.
Finish	Smooth faced.
Profile	-
Paver type	Regular plan form.
Arrises	Chamfered.
Interlocking features	Nibs.
Dimensions and associated tolerances	-
Nominal sizes	215 x 115 x 60 mm.
Arrises	Chamfered, 6 x 2 mm.
Weathering resistance	Class 3.
Abrasion resistance	≤ 23 mm. Guidance for specification option: Determined by Wide Wheel Abrasion Test.
Slip resistance	Unpolished Slip Resistance Value (USRV): ≥55; Potential for slip: Low.
Recycled content (minimum)	Guidance for specification option: Up to 10%, depending on site of manufacture.

Type	Hand lay.
Permeability	To BS DD 229:1996, 4265 mm/h.
Third-party certification	CE marked; BREEAM A rating as per the BRE Green Guide, 4th Edition 2009. Guidance for specification option: A+ rating can be achieved when used in conjunction with a prepared recycled sub-base.
Strength	Characteristic tensile splitting strength: ≥3.6 MPa; Failing load: ≥250 N/mm.
Unit weight	2.6 kg.
Accessories	None. Omega Flow marker block paving, yellow. Guidance for specification option: Depth to match block paving. Omega Flow marker block paving, white. Guidance for specification option: Depth to match block paving. Omega Flow marker block paving, black. Guidance for specification option: Depth to match block paving.
Tolerances on plan dimension and thickness nominal	Thickness: ±3 mm; Plan size: ±2 mm.
