OptiPlan-FB32 Fleeceback Single Ply - Warm Roof Build Up

Verified by manufacturer over a year ago

OptiTec Ltd Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

PVC-P sheet waterproofing warm roof system.

Jump to:
+ (0)1268 944054 Website

Application

Warm roofs.

Description

OptiPlan-FB32 is a fibre-glass reinforced, multi-component, fleece backed synthetic roof waterproofing membrane made from premium quality plasticized polyvinyl chloride (PVC-P). The upper light layer offers exceptional resistance to weather and UV rays, whilst the membrane underside features a laminated geotextile fleece, providing both a separating layer and a surface for applying adhesive. All rolls have a fleece-free selvedge to allow for secure and efficient hot air welding of the membrane. The product is also available with a slip resistant top surface.


Components:

  • OSA-5 Self-Adhesive Primer.
  • OSA Vapour Control Layer.
  • OTM-IA Insulation Adhesive.
  • OptiTherm Insulation.
  • OP-FBA12 Fleeceback Adhesive.
  • OP-FB32 Fleeceback Single Ply.


Features and benefits:

  • Manufactured using an advanced automated co-extrusion method.
  • ensuring reliable material uniformity.
  • Independently tested by the British Board of Agreement, BBA
  • certificate number 18/5529.
  • Outstanding resistance to weathering and UV radiation.
  • High resistance to impact and puncture.
  • High water vapour permeability.
  • Outstanding weldability and excellent flexibility in cold temperatures.
  • Full range of system accessories available.
  • Reliable resistance to wind load.
  • High tensile strength.
  • Recyclable.

General information

Color

Grey

Finish

Smooth

Material

PVC-P

Length

15000 mm

Width

2100 mm

Height

1.8 mm

Warranty description

20 year

Guidance for specification option:

Standard 20 year warranty - up to 25 year warranty available.

Uniclass

Ss_30_40_30_80 Single layer sheet warm roof covering systemsPrimary

CAWS

J42/10 Warm deck roof covering

J42/110 Warm deck roof covering

Specification data - Single layer sheet warm roof covering systems

Preparation

-

Horizontal work

OSA-5 Self-Adhesive Primer.

Guidance for specification option:

Solvent based primer for bonding a variety of self-adhesive membranes and vapour control layers to variety of substrates.


  • Chemical base: Synthetic rubber.
  • Solids content: 32–36%.
  • Application temperature: 5–30°C.
  • Coverage rate per litre: 4–8 m².
  • Colour: Black.


Air and vapour control layer

-

Type

O-SAV-SV Vapour Control Layer Silver.

Guidance for specification option:

A self-adhesive bituminous membrane that forms a barrier against vapour and gases. Consisting of a self-adhesive bituminous compound

re-enforced by a composite aluminium foil with integral glass-fibre mat.


  • Thickness: 0.6 mm.
  • Tensile strength: >600 N/50mm
  • Elongation at break: 5%.
  • Tear resistance (nail shank): 190 N.
  • Static load resistance: Met. A 5 kg | Met. B 20 kg.
  • Fire behaviour: Class E.

Insulation

-

Type

OptiTherm Insulation.

Attachment

OTM-IA Insulation Adhesive.

Waterproof covering

-

Type

OP-FB32 Fleeceback Single Ply.

Guidance for specification option:

  • Colour: RAL 7043.
  • Roll size: 2.1 x 15 m.
  • Mass per unit area: 2.1 kg/m².
  • Fleece weight: ≥180 g/m²/ 200 g/m².
  • Thickness: 1.5 mm.
  • Water tightness: ≥10 kPa.

Attachment

OP-FBA12 Fleeceback Adhesive.

Guidance for specification option:

A single component polyurethane adhesive that reacts with moisture which then cures to form a permanent strong bond that withstands both high and low temperatures.


  • Chemical Base: Polyurethane.
  • Solids content: 100%.
  • Viscosity: 3000–4000 cps (at 20°C).
  • Application temperature: 5–30°C.
  • Cure rate: 30 minutes (at 20°C).
  • Colour: Blue.

Sustainability data

Country of material origin

Germany

Country of product manufacture

Germany

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

OptiPlan PVC Single Ply BBA Certificate
