OptiTorch-Premium Felt - Safe to Torch Warm Roof Build Up
Verified by manufacturer over a year ago
BBA Agrément Certificate
Certificate type
Bituminous sheet waterproofing warm roof system.
Application
Warm roofs.
Description
OT-Premium Techno-58 is a polyester reinforced, slate covered torch-on cap sheet, saturated and coated with high quality SBS (Styrene-Butadiene-Styrene) modified bitumen. The membrane carrier is a tough polyester reinforcement, giving the material excellent dimensional stability and very high mechanical strength. The upper layer is coated with coarse-grained slate, protecting the membrane from ultraviolet exposure and the lower layer is finished with a thermofusible film for fast and consistent torch-on application. In addition, the membrane features the latest graphite firewall technology within its formulation and has been fully fire tested in accordance with EN 13501-5 and ENV1187:2002, Broof Test 4 (2-layer system).
Components:
- OB25 High Performance Bitumen Primer.
- OTP-T4U 4 kg Torch On Underlay.
- OTM-IA Insulation Adhesive.
- OptiTherm Torch Receivable Insulation.
- OB25 High Performance Bitumen Primer.
- OTP-T4U 4 kg Torch On Underlay.
- OTP-T58C Torch On Cap Sheet or OTP-AR66 Anti Root Cap Sheet.
Features and benefits:
- Independently tested by the British Board of Agreement, BBA certificate number 21/5854.
- Unique snowflake printed thermofusible film to guide accurate and consistent torch-on application.
- Incorporates graphite firewall technology for the ultimate in fire protection.
- Excellent low temperature flexibility at -25°C.
- High puncture resistance and resistance to foot marking.
- High quality polyester reinforcement.
General information
Color | Black Green |
Material | Bitumen |
Length | 1000 mm Guidance for specification option: Techno 58 Capsheet. 1080 mm Guidance for specification option: AR66 Capsheet. |
Width | 8000 mm Guidance for specification option: Techno 58 Capsheet. 5000 mm Guidance for specification option: AR66 Capsheet. |
Warranty description | 20 year Guidance for specification option: Standard. 25 year Guidance for specification option: Up to 25 years available (product and workmanship). |
Uniclass | |
CAWS | J42/110 Warm deck roof covering J42/10 Warm deck roof covering |
Specification data - Reinforced bitumen membrane warm roof covering systems
Preparation | |
Horizontal work | OB25 High Performance Bitumen Primer.Guidance for specification option: Solvent based bitumen primer for preparing dry or slightly damp substrates prior to bonding bituminous membranes and hot melt systems. The solvent blend used ensures the primer is quick drying and ready to apply membranes and hot melt in as little as 30 minutes at 20°C.
|
Insulation | |
Type | OptiTherm Insulation. |
Fixing | OTM-IA Insulation Adhesive. |
Waterproof covering | |
First layer | |
Type | OTP-T4U 4 kg Torch On Underlay.Guidance for specification option: polyester reinforced torch-on underlay, saturated and coated with high quality SBS (Styrene-Butadiene-Styrene) modified bitumen. The membrane carrier is a tough 160 g/m² polyester reinforcement, giving the material excellent dimensional stability and very high mechanical strength. The membrane is finished on both sides with a thermofusible film for fast and consistent torch-on application.
|
Attachment | Torch-on. |
Top layer | |
Type | OTP-AR66 Anti Root Cap Sheet.Guidance for specification option: Torch-applied, bituminous membrane which is saturated and coated with high quality SBS (Styrene-Butadiene-Styrene) modified bitumen. It has a 250 g/m² polyester fleece reinforcement and incorporates special additives which provides reliable protection from root growth. The 4 year tests for these additives were passed according to the FLL standards at the Botanic Institute Hamburg. Test certificates are available on request. In addition, OT-Premium AR66 Capsheet has been fully fire tested as part of a designated system in accordance with EN 13501-5 and DD CEN/TS 1187:2012, Broof Test 4.
OTP-T58C Torch On Cap Sheet.Guidance for specification option: Standard.
|
Attachment | Torch-on. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Third party certifications
BBA Agrément Certificate
OptiTorch-Premium BBA Certificate
Literature
OB25 Primer TDS
OT-Premium AR66 Capsheet TDS
OT-Premium Techno-58 Capsheet TDS
OT-Premium TO4 Underlay TDS
OptiTorch Premium Bituminous Felt Brochure
OptiTorch Warm Roof Build Up Standard Drawing Detail Pack
OptiTorch - Felt - Cold Roof Build Up - Detail Drawings
Case studies
Westminster Bridge Road
