Pendock Radius - GRG Column Casings - Glass Reinforced Gypsum Column Casings

Name: Pendock Radius - GRG Column Casings - Glass Reinforced Gypsum Column Casings
Brand: Pendock
SKU: 7dmzqKqsp1WxtfFhxv1UY

Verified by manufacturer 4 months ago

Pendock

Third party certifications:

Constructionline Gold
Certificate type

Column casings for interior use only for concealing structural steelwork and support columns.

Jump to:

+44 (0)1952 580 590 Website

Application

For interior use. Suitable for a range of applications including commercial buildings, hotels, and retail interiors, in both new build and refurbishment situations where structural elements need to be decoratively concealed.

Description

A range of glass reinforced gypsum column casings designed to be plastered or rendered and painted on site after installation. The casings are solely for interior use. They are strong, quick and easy to install, and offer an alternative to pre-finished columns in a wide range of applications, GRG columns are a suitable option where a seamless casing is required, where no visible joints are seen.

Features and benefits:

In addition to the standard ranges, bespoke items in almost any shape or size can be produced, with high levels of intricate detail.
The casings are manufactured from alpha-calcium sulfate semi-hydrate (plaster) with glass fibre matt
Casings are mechanically fixed to timber battens fixed to existing columns. Joints and fixings can be concealed using a plaster mix on site.
GRG casings are hand cast products and weight and density will vary.

General information

Color	Cream White Other
Finish	Smooth
Material	Gypsum
Shape	Circle Oval Other
Length	Bespoke
Width	Bespoke
Height	Bespoke

Uniclass	Pr_35_90_43_66 Preformed casingsPrimary
CAWS	P20/170 Proprietary P20/30 Proprietary

Specification data - Preformed casings

Material	GRG.
Finish as delivered	Smooth, ex-mould, unfinished white plaster designed to accept paint or any other finish made for an absorbent surface.
Colour	White.
Profile	Bespoke. Circular. Elliptical. Hexagonal. Oval. Semi Circular.
Size	- Manufacturer guidance 20–1000 mm diameter as standard; non-standard bespoke sizes also available. Consult manufacturer for details and insert requirements.

Accessories	None. Head collars, aluminium. Head collars, stainless steel. Skirting, aluminium. Skirting, stainless steel.
Height	3000 mm (standard height). Guidance for specification option: Shorter or longer lengths can be produced, together with bespoke sizes.
Thickness	12–15 mm. Guidance for specification option: Insert requirements.
