R-MER SEAM - Steel Standing Seam System
Verified by manufacturer 4 months ago
Low profile steel standing seam system with secret fix.
Application
- Suited to contemporary roof and wall applications.
- Suitable for building with low or medium humidity and for altitudes below 900 m.
Description
R-MER SEAM’s steel panels effortlessly click into place with a hidden fixing system, guaranteeing a streamlined installation process without compromising on sleek architectural design.
Features and benefits:
- 20 year single-point guarantee.
- Roof and wall applications.
- Secret fix installation.
- Low profile.
General information
Color | Grey Brown Other |
Finish | Coated |
Material | Steel |
Shape | Rectangle |
Length | 1800 mm Guidance for specification option: Minimum. 13000 mm Guidance for specification option: Maximum. Bespoke Guidance for specification option: Between 1800–13 000 mm. |
Width | 500 mm |
Height | 25 mm |
Warranty description | 20 year |
Uniclass | |
CAWS | H31/10 Metal H31/120 Metal |
Specification data - Metal profiled sheet self-supporting roof covering systems
Liner sheets | |
Material | Plywood/ OSB deck. |
Breather membrane | |
Material | Vapour-permeable sheets (Viking breather membrane). |
External sheets | |
Material | Steel profiled sheets. |
Primary fasteners | Secret fix clip to spacer with no penetration of sheet. |
Fascia | |
Material | Manufacturer guidanceConsult manufacturer and insert requirements. |
Soffit | |
Material | Manufacturer guidanceConsult manufacturer and insert requirements. |
Gutters | |
Material | Not required.Viking gutter system. |
System accessories | Not required.Ridge.Abutment at ridge.Hip.Change of level.Abutment at verge.Verge.Valley. |
Top surface colour | Anthracite Grey (RAL 7016). Grey Aluminium (RAL 9007). Traffic Grey (RAL 7042). Copper Brown (8004). |
Profile lengths | Manufacturer guidanceConsult manufacturer and insert requirements.
|
Thickness | 0.50 mm. |
Depth | 25 mm. |
Width | 500 mm. |
Weight | 5.75 kg/m². |
Sustainability data
Contains Red List materials | No |
Material | Steel |
