Raised Wall Panels - Acoustic Panel

Name: Raised Wall Panels - Acoustic Panel
Brand: Acoufelt
SKU: tsMG7z85zC5mz1nY7v5te6

Verified by manufacturer 11 days ago

Raised Wall Panels - 12 mm

Acoufelt

Product certifications:

HPDC Certification
Certificate type
SCS Indoor Advantage™ Gold
Certificate type
EN 13501-2018
Certificate type
Declare
Certificate type
ASTM
Certificate type

Acoustic wall panels made from FilaSorb™.

Jump to:

+44 (0) 203 488 6322 Website

Application

Acoustic panels for wall mounting suitable for use for various commercial educational applications.

Description

Raised wall panels featuring four depth options, offering limitless design possibilities: use a single depth for understated texture or combine varying depths to craft a dynamic, rhythmic aesthetic.

Customize looks with a monochromatic palette for refined simplicity, or introduce a second-colour backing to create a striking contrast and add character. With its balance of form and function, raised wall panels transform any interior into a visually engaging and acoustically optimized environment.

Features and benefits:

100% polyester.
Made from 60% (minimum) recycled content.
Generated using 40% solar energy.
Red list free declare label (third party verified).
Total VOC's less than 0.5 mg/m³ (third party verified).

General information

Color	Beige Black Blue Brown Cream Green Grey Ivory Orange Pink Red Turquoise White Yellow Other Show more Manufacturer guidance Available in 40 colourways.
Finish	Textured
Material	Polyester fibre (PET) Felt
Shape	Rectangle
Length	25 mm 50 mm 102 mm 152 mm Manufacturer guidance Depth.
Width	305 mm 610 mm 1220 mm Bespoke
Height	2440 mm 2800 mm Bespoke
Warranty description	20 year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K13/170 Acoustic panel lining K13/170 Acoustic panel lining

SKU Code	FISO12RICUST

Specification data - Sound attenuator infill units

Third-party certification	UKAS-accredited third-party testing organization.
Form	Panel.
Rigidity	Rigid.
Application	Wall mounting.
Material	FilaSorb™ polyester felt.
Material density	2.4 kg/m².
Acoustic performance	-
Purpose	Absorber.
Sound absorption	Class E/D to BS EN ISO 11654. Manufacturer guidance ISO 11654 -2002: acoustics - rating of sound absorption. NRC 0.45 - no air gap\| 0.25 (H) αw no air gap, Class E. NRC 0.54 - 12 mm air gap \| 0.35 (MH) αw 12 mm air gap, Class D. NRC 0.64 - 20 mm air gap \| 0.40 (MH) αw 20 mm air gap, Class D. *results are for material only.
Fire performance	-
Reaction to fire	To EN 13501-1, B-s1, d0.
VOC emissions	≤0.5 mg/m³.
Dimensions	-
Size (length x width)	- Manufacturer guidance Consult manufacturer and insert requirements. Width – 305, 610 or 1220 mm. Depth – 25, 50, 102 or 152 mm. Height – 2440 or 2800 mm.
Thickness (overall)	12 mm.
Profile	Linear.
Edges	Square.
Surface pattern	Solid.
Finish	Material.
Colour	Peppercorn. Currant. Carrot. Peach. Flamingo. Valentine. Turmeric. Wheat. Kale. Oregano. Sencha. Celery. Eucalyptus. Wasabi. Pistachio. Midnight. Flint. Granite. Denim. Iris. Azur. Marine. Stonewash. Periwinkle. Sea Salt. Shiraz. Piano Black. Charcoal. Slate. Grey. Metal. Platinum. Milkyway. Walnut. Umber. Amethyst. Quartz. Almond. Ivory. Pearl. White.
Accessories	- Manufacturer guidance Consult manufacturer and insert requirements or omit.

Colour fastness	To ISO 105-B02, 6–7.
Depth	37 mm fin depth. 62 mm fin depth. 123 mm fin depth.

Sustainability data

Contains Red List materials	No
Country of product manufacture	United Kingdom
Material	Polyester fibre (PET) Felt
Recyclability	Recyclable at end-of-life
Recycled content As defined in clause 7.8 of BS EN ISO 14021	60 %
