REGUPOL sonus isolation strip - Resilient Layer for partitions & joists
Verified by manufacturer 21 days ago
ISO 14001 Environmental Management Systems
Certificate type
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
Isolating strip.
Application
Suitable for use beneath all types of studwork and the isolation of flooring joists
Description
A composite rubber/ PUR strip designed to sit beneath all types of timber and steel studwork walls and partitions and walls to isolate noise and vibration at source. Also for on top of flooring joists
General information
Color | Black |
Finish | Rolled Smooth |
Material | Rubber Polyurethane (PUR) |
Shape | Other |
Length | 15000 mm |
Width | Bespoke |
Height | 6.00 mm |
Warranty description | One year Other |
Uniclass | |
CAWS | K10/115 Metal stud partition system K10/125 Metal stud partition system K10/205 Lining on timber K10/30 Metal stud |
Product range |
Specification data - Raised access floor panels
Width | 43 mm. 100 mm. 120 mm. 200 mm. Bespoke. Guidance for specification option: Other widths on request. |
Backing | None. Foil facing, Class 0. Self-adhesive. Manufacturer guidanceAvailable with a range of backings: consult manufacturer for details. |
Thickness | 6 mm. |
Temperature resistance | -40–+110ºC. |
Modulus of elasticity | Static modulus of elasticity: 1.20–1.90 N/mm²; |
Compression component | 4.60%. Guidance for specification option: DIN 53572, 50% deformation at 23ºC for 72 hours. |
Length | 1250 mm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Rubber Polyurethane (PUR) |
Recyclability | Recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 85 % |
Third party certifications
Third party certifications
ISO 14001 Environmental Management Systems
ISO14001
ISO 45001 Health and Safety Management
ISO 45001:2018
ISO 9001 Quality Management
SIG ISO 9001
Literature
REGUPOL Studwork and Joist Isolation Strip
REGUPOL sonus 3912 Isolation Strip
REGUPOL sonus isolation strip (REGUPOL 3912)
