RhinoGuard® Lift Assist Bollard - Stainless Steel/ Steel Bollard

Verified by manufacturer over a year ago

RhinoGuard® 35/30 Lift Assist Protective Bollard Stainless Steel

Marshalls Landscape Protection & Street Furniture Variant:

Lift assist protective bollard

Jump to:
0370 600 2425 Website

Application

  • Protective barrier for use in public spaces.
  • Landscape protection.

Description

The Rhinoguard® 35/30 protective bollard is an effective solution for designers looking to implement an attractive, protective barrier in public spaces.


The design features hand-operated lift assist for areas that still require vehicle access. The lift assist design weighs 20kg and features a gas spring, which enables easier lowering of the bollard for permitted vehicular access. The 35/30 model is manufactured using galvanized steel and has been rigorously crash-tested to meet the requirements of IWA-14, which measures impact performance. Depending on requirements the 35/30 core can be sleeved with a choice of brushed stainless steel or steel with a powder coat finish.


This product is capable of withstanding a 3.5 tonne vehicle travelling at 30mph. The security classification is V/3500(N1)/48/90:01.


Features and benefits:

  • Stainless steel sleeve available
  • Easy to lower for access
  • Static or lift assist options, depending on project requirements
  • Lift assist design features a rubber cover to reduce water and dirt blockage as well as a drainage port for rain water

General information

Color

Silver

Black

White

Grey

Blue

Show more

Finish

Brushed

Galvanized

Powder-coated

Material

Steel

Stainless steel

Shape

Other

Length

1400 mm

Width

154 mm

Manufacturer guidance

Sleeve diameter.

Height

1000 mm

Uniclass

Pr_20_76_08_82 Stainless steel bollardsPrimary

CAWS

Q50/31 Bollards

Q50/190 Bollards

Specification data - Stainless steel bollards

Standard

In accordance with IWA-14.

Dimensions

-

Size and profile

154 mm.

Manufacturer guidance

Sleeve diameter.

Height

1000 mm.

Length below ground

1400 mm.

Top profile

Flat.

Base

Lift assist.

Finishes

-

Worked finishes

Brushed.

Applied finishes

Not required.

Retro-reflective tape.

Accessories

Guidance for specification option:

Consult manufacturer and insert requirement or omit.

Colour

Stainless steel.

Bollard Sleeve Topping

Grade 316 stainless steel.

Weight

81 kg.

Internal diameter

139 mm.

Manufacturer guidance

Core diameter.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Literature

HVM Landscape Protection (Hostile Vehicle Mitigation)

HVM Landscape Protection (Hostile Vehicle Mitigation)
